Use Cases
SICAM A8000 / CP-8000 • CP-8021 • CP-8022 Manual Unrestricted 593
DC8-037-2.02, Edition 10.2017
Example A
This example shows the usage of 2 static routes from CP-8000, CP-8021 or CP-8022 via
2 gateways to control center in different IP networks.
SICAM A8000
IEC 61850
60870-104
IEC 61850
60870-104
ESC
CP-8021
CP-8022
CP-8000
X4
X1
Control Center B
255.255
IP address
Subnet mask
172.16.50.2
.255.0
Control Center D
255.255
IP address
Subnet mask
172.16.51.2
.255.0
IP address
Subnet mask
172.16.50.100
.255.0 255.255
Cisco Router
255.255
Gateway IP address - Route 0
IP address
Subnet mask
192.168.94.250
.255.0
IP address
Subnet mask
172.16.51.100
.255.0 255.255
Control Center A
255.255
Destination IP address - Route 0
IP address
Subnet mask
172.16.50.1
.255.0
Master Modul:
1 IP address
192.168.94.1
255.255.255.0
192.168.94.250
Mode of Ethernet Ports
Own IP address
Subnet mask
Default gateway
Source IP address - Static route 0
Source IP address
Source IP address
192.168.94.1
192.168.94.1
Source IP address - Static route 1
Static route 1
Static route 0
Control Center C
255.255
Destination IP address - Route 1
IP address
Subnet mask
172.16.51.1
.255.0
Cisco Router
255.255
Gateway IP address - Route 1
IP address
Subnet mask
192.168.94.251
.255.0
Substation Zone
Control Center Zone 1 Control Center Zone 2
