Commissioning (software)
5.9 Commissioning with PROFIBUS DP
Control Units CU240S
Operating Instructions, 11/2006, A5E00766042B AA
5-97
Note
Drive ES SIMATIC provides function blocks for parameter write/read tasks within standard
block libraries and some examples.
Error values in DPV1 parameter responses
Table 5-39 Error values in DPV1 parameter responses
Error
value
Meaning Note Extra info
0x00 Illegal parameter number Access to a parameter which does not
exist.
–
0x01 Parameter value cannot be changed Modification access to a parameter
value which cannot be changed.
Subindex
0x02 Lower or upper value limit exceeded Modification access with value outside
value limits.
Subindex
0x03 Invalid subindex Access to a subindex which does not
exist.
Subindex
0x04 No array Access with subindex to an unindexed
parameter.
–
0x05 Wrong data type Modification access with a value which
does not match the data type of the
parameter.
–
0x06 Illegal set operation (only reset
allowed)
Modification access with a value not
equal to 0 in a case where this is not
allowed.
Subindex
0x07 Description element cannot be
changed
Modification access to a description
element which cannot be changed.
Subindex
0x09 No description data Access to a description which does not
exist (the parameter value exists).
–
0x0B No operating priority Modification access with no operating
priority.
–
0x0F No text array exists Access to a text array which does not
exist (the parameter value exists).
–
0x11 Request cannot be executed due to
operating status
Access is not possible temporarily for
unspecified reasons.
–
0x14 Illegal value Modification access with a value which
is within the limits but which is illegal
for other permanent reasons
(parameter with defined individual
values).
Subindex
0x15 Response too long The length of the present response
exceeds the maximum transfer length.
–
