Functions
8.2 Data Sets
Control Units CU240S
Operating Instructions, 11/2006, A5E00766042B AA
8-7
The parameters, combined in a command data set, are designated with [x] in the parameter
list in the index field.
Index
Pxxxx[0] Command data set 0 (CDS0)
Pxxxx[1] Command data set 1 (CDS1)
Pxxxx[2] Command data set 2 (CDS2)
Note
A complete list of all of the CDS parameters is contained in the Parameter Manual.
It is possible to parameterize up to three command data sets. This makes it easier to toggle
between various pre-configured signal sources by selecting the appropriate command data
set. A frequent application involves, for example, the ability to toggle between automatic and
manual operation.
Note
The parameters will be altered during data set switchover in the state "Ready" and "Run".
The following parameters will not be changed in the state "run:
P0700, P0701, P0702, P0703, P0704, P0705, P0706, P0707, P0708, P0709, P0712, P0713,
P0719, P0800, P0801, P0840, P0842, P0844, P0845, P0848, P0849, P0852, P1000, P1020,
P1021, P1022, P1023, P1035, P1036, P1055, P1056, P1070, P1071, P1075, P1076, P1110,
P1113, P1124, P1140, P1141, P1142, P1330, P1500, P1501, P1503, P1511, P1522, P1523,
P2103, P2104, P2106, P2220, P2221, P2222, P2223, P2235, P2236.
SINAMICS G120 has an integrated copy function which is used to transfer command data
sets.
This can be used to copy CDS parameters corresponding to the particular application.
P0809 is used to control the copy operation as follows:
Copy operation controlled with P0809
P0809[0] Number of the command data set which is to be
copied (source)
P0809[1] Number of the command data set into which data
is to be copied (target)
Copying is started, if P0809[2] = 1 P0809[2]
Copying has been completed, if P0809[2] = 0
