Functions
8.18 Fail-safe functions
Control Units CU240S
Operating Instructions, 11/2006, A5E00766042B AA
8-135
Case 4: SLS monitoring > Frequency setpoint
Initiation of SLS =>
• SLS monitoring activated
• SLS-LED flashing
If frequeny setpoint runs above SLS monitoring an STO is triggered
immediately
Deactivation of SLS =>
• SLS monitoring off
• SLS-LED off
• To start again, STO must be
acknowledged and a new on command
is necesarry to ramp up to frequency
setpoint.
