Communications configuring
System- and communication configuring D7-SYS - SIMADYN D 3-109
Edition 12.2003
•
Communications reference :
Type
:
Non-cyclic client
Association type : Local LSAP :
Remote address : Remote LSAP :
Max. PDU length : 241 Monitoring interval : 0 s
Password : 0 Group : 0
Profile : 0 0
Supported utility :
Read : no Write : no
Get OV (detailed version) : no
Symbolic addressing : no
Max. No. of parallel tasks:
Transmitting : 1 Receiving : 0
Name :
Table 3-48 Mask, "Non-cyclic client"
Rules:
• The communications reference must correspond with the CFC
configuring (address stage 1 at address I/O).
• "MMAZ" is the association type when establishing a connection to a
master (e. g. SIMADYN D or SIMATIC) or "MSZY" when establishing
a connection to a slave.
• Local LSAP is uncritical, if the server association is "open" otherwise it
must correspond with "Remote LSAP" for the server.
• Remote address and remote LSAP uniquely address the server.
• Max. PDU length should only be changed if the server cannot handle
the specified length.
• The monitoring interval must correspond with that of the server.
