110 DCA Vantage Operator’s Guide
Maintenance
Calibrating the Touchscreen
Calibrate the touchscreen if it does not respond correctly when you touch the
screen.
1. At the System Test menu, select
Calibrate Touchscreen.
2. When the Touchscreen Calibration screen displays, select the
X target at
the center of the screen.
3. Repeat when prompted at each corner.
The Touchscreen Calibration Complete screen displays.
User System Test Results
The User System Test Results screen displays the status of each system test
you selected at the User System Test menu screen. The results display after
the tests that require user action are complete and while the automatic tests
are running on the system.
NOTE: You can cancel the tests while they are running.
System Settings
Use the System Settings menu to set and review the following system
settings:
• change the sound volume
• adjust the contrast of the display
• access additional settings for the system
• view the current setting for the system
NOTE: You must restart the system if you restore system settings.
Ethernet Port
After connecting to a valid network connection, the
system automatically runs the test.
USB Port
After connecting a USB device, the system
automatically runs the test.
Lamp
The system automatically runs the test.
Motor Control
The system automatically runs the test.
Measurement
System
The system automatically runs the test.
If you select . . . then. . .
