HMI menu ID Parameter Description Default value
[unit]
Value range Access
level
2.4.3.6.11 Fail-safe minimum time Minimum time the output stays
in fail-safe mode. Short events
will be prolonged.
0
● 0 to 100 s
User
2.4.3.7 Pulse output
2.4.3.7.1 Redundancy mode Set the redundancy mode. The
pulses on channel 3 will follow
pulses on channel 2 with 90 or
180 deg. shift.
Off
● Off
● 90º
● 180 º
User
2.4.3.7.2 Process value Select process value for current
output.
Mass flow
● Mass flow
● Volume flow
● Standard
volume flow
● Fraction flow
A
● Fraction flow
B
User
2.4.3.7.3 Direction Select measured flow direction.
The flow meter will only output
current when flow value is meas‐
ured in selected direction.
Positive
● Positive
● Negative
● Bidirectional
User
2.4.3.7.4 Pulse units Select units for pulse output.
Units are not applied at commu‐
nication interface.
Mass flow
kg
● g (grams)
● kg (kilograms)
● t (1 t = 1000
Kg)
● STon (1 STon
= 2000 lb)
● T (1 T = 2240
lb)
● oz (ounces)
● lb (pounds)
● Custom
User
Default settings
B.5 Inputs and outputs
