HMI menu ID Parameter Description Default value
[unit]
Value range Access
level
2.4.3.7.4 Pulse units Select units for pulse output.
Units are not applied at commu‐
nication interface.
Volume flow
l (liters)
● l (liters)
● hl (hectoliters)
● m
3
(cubic
meters)
● gal (US
gallons)
● gal (UK)
(imperial
gallons)
● bbl (US liquid
barrels = 31.5
US gallons)
● bbl-beer (beer
barrels = 31
US gallons)
● bbl-beer (beer
barrels = 42
US gallons)
● In
3
(cubic
inches)
● ft
3
(cubic feet)
● yd
3
(cubic
yards)
● bu (bushels)
● Custom
User
2.4.3.7.4 Pulse units Select units for pulse output.
Units are not applied at commu‐
nication interface.
Standard volume flow
Sl (standard lit‐
ers)
● Nl (normal
liters)
● Nm
3
(normal
cubic meters)
● SI (standard
liters)
● Sft
3
(standard
cubic feet)
● Sm
3
(standard
cubic meters
● Custom
2.4.3.7.5 Amount Define the amount per pulse, or
multiple pulses if you configure
more than 1 pulse per amount
1 User
2.4.3.7.6 Pulses per amount Define number of pulses which
will be output when configured
amount is reached
1 User
Default settings
B.5 Inputs and outputs
MASS 2100 & FC300 (FCT030)
316 Operating Instructions, 06/2017, A5E39789040-AA
