Siemens FC300 - Page 441

HMI menu ID Parameter Description Default value
[unit]
Value range Access
level
3.4.3.2.3 Error status Error status - Current
● Upper
saturation
● Lower
saturation
● Fail-safe
behaviour
avtive
● Cable breal
● Loop current
deviation
Read
only
3.4.3.2.4 Pulse counter Actual value of output pulses. Read
only
3.4.3.2.5 Reset pulse counter Status of the reset pulse counter Read
only
3.4.3.3 Channel 3 – input/output
3.4.3.3.1 Operation mode Set the output functionality you
want the channel to operate.
Status output
● Off
● Current output
● Frequency
output
● Pulse output
● Status output
Read
only
3.4.3.3.2 Digital input value Select the digital input value Read
only
3.4.3.3.2 Totalized amount Actual value of totalized amount. [kg] Read
only
3.4.3.3.2 Output frequency Actual value of frequency output. [Hz] Read
only
3.4.3.3.2 Digital output signal Actual value of status output. Read
only
3.4.3.3.2 Loop current Actual value of current output [mA] Read
only
3.4.3.3.3 Error status Error status - pulse
● Upper
saturation
● Fail-safe
behaiviour
active
Read
only
3.4.3.3.3 Error status Error status - frequency
● Upper
saturation
● Lower
saturation
● Fail-safe
behaiviour
active
Read
only
Default settings
B.9 Maintenance and diagnostics
MASS 2100 & FC300 (FCT030)
Operating Instructions, 06/2017, A5E39789040-AA 441
