Siemens LMS14

115/617
Building Technologies Division User Manual LMS14... CC1U7471en
5 Handling 28.01.2015
Line no.
Operating line
Default value Min Max Unit
Operator unit ACS420 ACS700/ACS790
2
8774 Flow temp setpoint 2 FlowTmpSetpResult HC2 Flow temp setpoint resulting HC2 - 0.0 140 °C
8779 Room thermostat 2
No demand ¦ Demand
Room thermostat HC2
No demand ¦ Demand
Room thermostat heating circuit 2
No demand ¦ Demand
No demand
8790 Heating circuit pump 3
Off ¦ On
HC Pump 3
Off ¦ On
State heating circuit pump 3
Off ¦ On
Off -
8791 HC mixing valve 3 open
Off ¦ On
HC MixValve 3 open
Off ¦ On
State heating circuit mixing valve 3
opening
Off ¦ On
Off
8792 HC mixing valve 3 closed
Off ¦ On
HC MixValve 3 close
Off ¦ On
State heating circuit mixing valve 3
closing
Off ¦ On
Off
8795 Speed heating circuit pump 3 HeatCircuitSpeed HC3 Heat circuit pump speed HC3 0 0 100 %
8800 Room temp 3 RoomTemp act value 3 Room temperature actual value 3 - 0.0 50 °C
8801 Room setpoint 3 RoomTemp Setp 3 Room temperature setpoint 3 - 4.0 35 °C
8802 Room temp 3 model RoomTempModel 3 Room temperature model 3 - 0.0 50 °C
8803 Flow temp setpoint 3 FlowTempSetp res HC3 Flow temperature setpoint resulting
HC3
- 0.0 140 °C
8804 Flow temp 3 FlowTmp act HeatCirc3 Flow temp actual value heat circuit
3
- 0.0 140 °C
8809 Room thermostat 3
No demand ¦ Demand
Room thermostat HC3
No demand ¦ Demand
Room thermostat heating circuit 3
No demand ¦ Demand
No demand
8820 DHW pump
Off ¦ On
DHW ChargPump
Off ¦ On
State DHW pump
Off ¦ On
Off -
8825 Speed DHW pump DHW pump speed DHW pump speed 0 0 100 %
8826 Speed DHW interm circ pump DHWInterCirPump speed DHW intermediate circuit pump
speed
0 0 100 %
8827 Speed inst DHW heater pump SpeedInstanHeaterPump Speed instantaneous heater pump 0 0 100 %
8830 DHW temp 1 DHW TempActTop B3/BMU DHW temperature actual value top
(B3)
- 0.0 140 °C
8831 DHW temp setpoint DHW Setp current DHW temperature setpoint current - 8.0 80 °C
8832 DHW temp 2 DHW TempActBott B31 DHW temperature actual value
bottom (B31)
- 0.0 140 °C
8835 DHW circulation temp DHW Circ temp DHW circulating temperature - 0.0 140 °C
8836 DHW charging temp DHW charging temp DHW charging temperature - 0 140 °C
