Building Technologies Division User Manual LMS14... CC1U7471en
5 Handling 28.01.2015
Line no.
Operating line
Default value
Min
Max
Unit
Operator unit ACS420 ACS700/ACS790
8852 DHW consumption temp DHW consumption temp DHW consumption temp - 0 140 °C
8853 Instant WH setpoint DHW instan heat setp DHW instantaneous heater setpoint - 0 140 °C
8860 DHW flow DHW flow DHW flow - 0 30 l/min
8875 Flow temp setp VK1 Flow temp setp VK1 Flow temp setpoint VK1 - 5 130 °C
8885 Flow temp setp VK2 Flow temp setp VK2 Flow temp setpoint VK2 - 5 130 °C
8895 Flow temp setp swimming pool Flow temp setp pool Flow temp setp swimming pool - 5 130 °C
8900 Swimming pool temp ActSwimmPoolTemp B13 Actual value of the swimming pool
temp B13
0 0 140 °C
8901 Swimming pool setpoint SetpointTempSwimmPool Setpoint temperature swimming
pool
24 8 80 °C
8930 Primary controller temp Prectrl actual value Precontroller actual value - 0.0 140.0 °C
8931 Primary controller setpoint Precontr setpoint Precontroller setpoint - 0.0 140.0 °C
8950 Common flow temp SegmFlowTmp actual Segment flow temperature actual
value
-
0.0 140.0 °C
8951 Common flow temp setpoint Segm FlowTmp setpoint Segment flow temperature setpoint - 0.0 140.0 °C
8952 Common return temp Segm RetTmp Segment return temp 0 0 140 °C
8962 Common output setpoint PowerSetpSegment Power setpoint segment 0 0 100 %
8980 Buffer temp 1 BufferTmp act top Buffer temp actual value top (B4) - 0.0 140.0 °C
8981 Buffer setpoint Buffer Setpoint Buffer storage tank setpoint 0 0 140 °C
8982 Buffer temp 2 BufferTmp act bottom Buffer temp actual value bottom
(B41)
- 0.0 140.0 °C
8983 Buffer temp 3 BufferTmp act middle Buffer temp actual value middle
(B42)
0 0 140 °C
9005 Water pressure H1 Water Pressure H1 Water pressure H1 - 0.0 10.0 bar
9006 Water pressure H2 Water Pressure H2 Water pressure H2 - 0.0 10.0 bar
9009 Water pressure H3 Water Pressure H3 Water pressure H3 0 0 10 bar
9031 Relay output QX1
Off ¦ On
Multifunct Relay QX1
Off ¦ On
State multifunctional relay (QX1)
Off ¦ On
Off -
9032 Relay output QX2
Off ¦ On
Multifunct Relay QX2
Off ¦ On
State multifunctional relay (QX2)
Off ¦ On
Off -
9033 Relay output QX3
Off ¦ On
Multifunct Relay QX3
Off ¦ On
State multifunctional relay (QX3)
Off ¦ On
Off -
9034 Relay output QX4
Off ¦ On
Multifunct Relay QX4
Off ¦ On
State multifunctional relay (QX4)
Off ¦ On
Off
9050 Relay output QX21 module 1 Multi Relay QX21 Mod1 State multifunctional relay (QX21 Off -
