Siemens LMS14

117/617
Building Technologies Division User Manual LMS14... CC1U7471en
5 Handling 28.01.2015
Line no.
Operating line
Default value Min Max Unit
Operator unit ACS420 ACS700/ACS790
Off ¦ On Off ¦ On
Modul 1)
Off ¦ On
9051 Relay output QX22 module 1
Off ¦ On
Multi Relay QX22 Mod1
Off ¦ On
State multifunctional relay (QX22
Modul 1)
Off ¦ On
Off
-
9052 Relay output QX23 module 1
Off ¦ On
Multi Relay QX23 Mod1
Off ¦ On
State multifunctional relay (QX23
Modul 1)
Off ¦ On
Off
-
9053 Relay output QX21 module 2
Off ¦ On
Multi Relay QX21 Mod2
Off ¦ On
State multifunctional relay (QX21
Modul 2)
Off ¦ On
Off
-
9054 Relay output QX22 module 2
Off ¦ On
Multi Relay QX22 Mod2
Off ¦ On
State multifunctional relay (QX22
Modul 2)
Off ¦ On
Off
-
9055 Relay output QX23 module 2
Off ¦ On
Multi Relay QX23 Mod2
Off ¦ On
State multifunctional relay (QX23
Modul 2)
Off ¦ On
Off
-
9056 Relay output QX21 module 3
Off ¦ On
Multi Relay QX21 Mod3
Off ¦ On
State multifunctional relay (QX21
Modul 3)
Off ¦ On
Off
-
9057 Relay output QX22 module 3
Off ¦ On
Multi Relay QX22 Mod3
Off ¦ On
State multifunctional relay (QX22
Modul 3)
Off ¦ On
Off
-
9058 Relay output QX23 module 3
Off ¦ On
Multi Relay QX23 Mod3
Off ¦ On
State multifunctional relay (QX23
Modul 3)
Off ¦ On
Off
-
[2481.1]
2ndSpeed HC Pump Q21
Off ¦ On
State 2nd speed heating circuit
pump (Q21)
Off ¦ On
Off
-
[1219.1]
OptgMode Ch'over HC1
Inactive ¦ Active
Operating mode changeover
heating circuit 1
Inactive ¦ Active
Inactiv
e
-
[2482.1]
2nd Speed HC Pump Q22
Off ¦ On
State 2nd speed heating circuit
pump (Q22)
Off ¦ On
Off
-
