Siemens LMS14

118/617
Building Technologies Division User Manual LMS14... CC1U7471en
5 Handling 28.01.2015
Line no.
Operating line
Default value Min Max Unit
Operator unit ACS420 ACS700/ACS790
[1219.2]
OptgMode Ch’over HC 2
Inactive ¦ Active
Operating mode changeover
heating circuit 2
Inactive ¦ Active
Inactiv
e
-
[2483.1]
2nd speed HCPump Q23
Off ¦ On
Stat 2nd speed heating circuit pump
(Q23)
Off ¦ On
Off
-
[1219.3]
OptgModeCh’over HC3/P
Inactive ¦ Active
Operating mode changeover HC3/P
Inactive ¦ Active
Inactiv
e
-
[2478.1]
El ImmHeater DHW
Off ¦ On
State electric immersion heater
DHW
Off ¦ On
Off
-
[2468.1]
DHW CircPump Q4
Off ¦ On
State DHW circulating pump (Q4)
Off ¦ On
Off
-
[1208.1]
OptgModeCh’over DHW
Inactive ¦ Active
Operating mode changeover DHW
Inactive ¦ Active
Inactiv
e
-
[2477.1]
Pump H1 Q15
Off ¦ On
Status H1 pump (Q15)
Off ¦ On
Off
-
[2484.1]
Pump H2 Q18
Off ¦ On
State pump H2 (Q18)
Off ¦ On
Off
-
[2718.1]
Pump H3 Q19
Off ¦ On
State pump H3 (Q19)
Off ¦ On
Off
-
[2495.1]
Primary pump Q14
Off ¦ On
Status primary pump (Q14)
Off ¦ On
Off
-
[2239.1]
PreC MixVlv opens Y19
Off ¦ On
Status precontroller mixing valve
opens (Y19)
Off ¦ On
Off
-
[2240.1]
PreCMixVlv close Y19
Off ¦ On
Status precontroller mixing valve
closes (Y20)
Off ¦ On
Off
-
[2496.1]
HeatGenLock (Y4)
Off ¦ On
Output heat generation lock (Y4)
Off ¦ On
Off
-
[2775.1]
TSP 5 Relay K13
Off ¦ On
Status time program 5 relays (K13)
Off ¦ On
Off
-
[2776.1]
Return temp valve Y15
Off ¦ On
Status return temp valve (Y15)
Off ¦ On
Off
-
