Siemens LMS14

119/617
Building Technologies Division User Manual LMS14... CC1U7471en
5 Handling 28.01.2015
Line no.
Operating line
Default value Min Max Unit
Operator unit ACS420 ACS700/ACS790
[2818.1]
Heat demand K27
Off ¦ On
Status heat demand (K27)
Off ¦ On
Off
-
[2824.1]
InstantHeater pump Q34
Off ¦ On
Status instantaneous heater pump
(Q34)
Off ¦ On
Off
-
[2821.1]
StorageTransferPmpQ11
Off ¦ On
State storage transfer pump (Q11)
Off ¦ On
Off
-
[2822.1]
DHW stiring pump Q35
Off ¦ On
State DHW stirring pump (Q35)
Off ¦ On
Off
-
[2823.1]
DHWInterCircuitPmpQ33
Off ¦ On
DHW intermediate circuit pump
(Q33)
Off ¦ On
Off
-
[2729.1]
Flowswitch
Off ¦ On
Flowswitch
Off ¦ On
Off
-
[2479.1] Alarm Relay K10
Off | On
State alarm relay (K10)
Off ¦ On
Off
[4455.1] Status output K35
Off | On
State of status output (K35)
Off ¦ On
Off
[4456.1] Status Info K36
Off | On
State of status information (K36)
Off ¦ On
Off
[4457.1] Gas damper K37
Off | On
State of flue gas damper (K37)
Off ¦ On
Off
[4458.1] Fan shutdown K38
Off | On
State of fan shutdown (K38)
Off ¦ On
Off
[6196.1] Delta-T contr 1 K21
Off | On
Status delta-T controller 1 K21
Off ¦ On
Off
[6197.1] Delta-T contr 2 K22
Off | On
Status delta-T controller 2 K22
Off ¦ On
Off
Burner control
