Siemens LMS14

120/617
Building Technologies Division User Manual LMS14... CC1U7471en
5 Handling 28.01.2015
Line no.
Operating line
Default value Min Max Unit
Operator unit ACS420 ACS700/ACS790
9500 Prepurge time Pre-ventilation time Pre-ventilation time 10 0 51 s
9501 Prepurge time min Prepurge time min Prepurge time min 10 0 51 s
9504 Required speed prepurging Req fan sp prepurging Required fan speed during
prepurging
2400 200 10000 min
-1
9505 Req speed prepurging min ReqSpeedPrepurgMin Req speed prepurging min 2400 200 10000 min
-1
9506 Speed tolerance prepurging Speed tol prepurg Speed tolerance prepurging 600 50 1200 min
-1
9512 Required speed ignition Speed req ignition Speed required at ignition load 2700 200 10000 min
-1
9513 Required speed ignition max Req SpeedIgnitMax Required speed ignition max 2700 200 10000 min
-1
9514 Speed tolerance ignition Speed tol ignition Speed tolerance ignition 600 50 1200 min
-1
9517 Preignition time Preignition time Preignition time 1 0,4 20 s
9518 Safety time Safety time Safety time 5 1,8 9,8 s
9519 Safety time with ignition Safety time ignition Safety time with ignition 4,6 0,2 9,6 s
9524 Required speed LF Req speed LF Required speed LF 1250 0 10000 min
-1
9525 Required speed LF min Req speed LF min Required speed LF min 1250 0 10000 min
-1
9526 Speed tolerance LF Speed tol LF Speed tolerance LF 600 50 1200 min
-1
9529 Required speed HF Req speed HF Required speed HF 6000 0 10000 min
-1
9530 Required speed HF max Req speed HF max Required speed HF max 6000 0 10000 min
-1
9531 Speed tolerance HF Speed tol HF Speed tolerance HF 600 50 1200 min
-1
9534 Optg time with ignition load Optg time ignit load Optg time with ignition load 1 0,2 10 s
9540 Postpurge time After-ventilation Time After-ventilation time 5 0 51 s
9541 Postpurge time TL max PostpurgeTime TL max Max. overrun time when TL / LT
cuts out
5 0 10 Min
9542 Postpurge time min Postpurge time min Postpurge time min 5 0 51 s
9544 Postpurge time 2 Postpurge time 2 0,2 0,2 51 s
9545 Postpurging in lockout pos
Off | On
PostPurg lock pos
Off | On
Postpurging in lockout position
Off | On
Off
9551 Required speed stop max Req speed stop max Required speed stop max 300 0 2000 min
-1
9610 Capacity
Up to 70 kW ¦ Up to 120 kW ¦ Above 120 kW
Capacity
Up to 70 kW ¦ Up to 120 kW ¦ Above 120
kW
Capacity
Up to 70 kW ¦ Up to 120 kW ¦ Above 120
kW
Up to 70kW -
9611 LP configuration
LP mode 1 ¦ LP mode 2 ¦ LP mode 3 ¦ LP mode 4 ¦
LP mode 5
LP configuration
LP mode 1 ¦ LP mode 2 ¦ LP mode 3 ¦ LP
mode 4 ¦ LP mode 5
LP configuration
LP mode 1 ¦ LP mode 2 ¦ LP mode 3 ¦ LP
mode 4 ¦ LP mode 5
LP mode 1 -
9612 GP configuration GP configuration GP configuration GP not connected -
