Building Technologies Division User Manual LMS14... CC1U7471en
5 Handling 28.01.2015
Line no.
Operating line
Default value Min Max Unit
Operator unit ACS420 ACS700/ACS790
GP not connected ¦ GP connected GP not connected ¦ GP connected GP not connected ¦ GP connected
9613 Home run mode
Startup with home run ¦ Startup without
home run
Home run mode
Startup with home run ¦ Startup without
home run
Startup with home run -
9614 Postpurging level
Run ¦ Prepurge
Postpurging level
Run ¦ Prepurge
Postpurging level
Run ¦ Prepurge
Run -
9615 Forced prepurging on error
Off ¦ On
Forced prepurg error
Off ¦ On
Forced prepurging on error
Off ¦ On
On -
9616 Max speed Max speed Max speed 10000 0 10000 min
-1
9617 Hall sensor pulses/rev Hall sens pulses/rev Hall sensor pulses/rev 2 0 6 -
9618 Ion curr level extran light IonCurrLevExtranLight Ion curr level extran light 0.61 0 100 µA
9619 Ion curr level flame exting IonCurrLevFlameExting Ion curr level flame exting 0.78 0 100 µA
9626 Fan output/speed slope FanOutput/speed slope Fan output/speed slope
0 -1000 1000 -
9627 Fan output/speed Y-section FanOutp/speed Y-sec Fan output/speed Y-section
0 -1500 1500 -
9630 Speed Kp Speed Kp Speed Kp 1,125 0 15,9375 -
9631 Speed Tn Speed Tn Speed Tn 8 0 600 s
9632 Speed Tv Speed Tv Speed Tv 0 0 1.75 s
9650 Chimney drying
Off ¦ Temporarily ¦ Permanently
Chimney drying
Off ¦ Temporarily ¦ Permanently
Chimney drying
Off ¦ Temporarily ¦ Permanently
Off -
9651 Req speed chimney drying Req speed chimney dry Req speed chimney drying 500 0 10000 min
-1
9652 Duration chimney drying Duration chimney dry Duration chimney drying 10 10 1440 Min.
[3694.1]
Pt1 time const 1 drop Pt1 time constant 1 on falling speed 7 0 100 s
[3695.1]
Pt1 time const 2 drop Pt1 time constant 2 on falling speed 6 0 100 s
[3696.1]
Pt1 time const 3 drop Pt1 time constant 3 on falling speed 5 0 100 s
[5283.1] Pt1 time const 4 drop Time constant 4 falling
0 0 100 s
[5284.1] Pt1 time const 1 incr Time constant 1 rising
0 0 100 s
[3697.1]
Pt1 time const 2 incr Pt1 time constant on rising speed 0 0 100 s
[5285.1] Diff setpoint filter
No ¦ Yes
Lower setpoint filter
No ¦ Yes
No -
[3698.1]
Pt1 upper spd falling Pt1 upper speed threshold falling 3710 0 10000 min
-1
[3699.1]
Pt1 lower spd falling Pt1 lower speed threshold falling 2010 0 10000 min
-1
[3997.1]
Fan PWM-Min Lower limit manipulated variable fan 0 0 100 %
[3998.1]
Fan PWM-Max Upper limit manipulated variable fan 100 0 100 %
[4269.1]
Ion curr lim, low Ionization current limitation low limit 0 0 100 µA
