Building Technologies Division User Manual LMS14… CC1U7471en
6 The settings in detail 28.01.2015
6.22 Delta-T controller
The Delta-T controller function can be used in three different ways:
1. For monitoring temperature overshoot
2. For monitoring temperature undershoot
3. As a differential temperature controller
Line no. Operating line
Controller 1 Controller 2
5570 5580 Temp diff on dT contr 1, 2
5571 5581 Temp diff off dT contr 1, 2
Line no. Operating line
Controller 1 Controller 2
5572 5582 On temp min dT contr 1, 2
Line no. Operating line
Controller 1 Controller 2
5573 5583 Sensor 1 dT controller 1, 2
None
DHW sensor B31
Collector sensor B6
Return sensor B7
DHW circulation sensor B39
Buffer sensor B4
Buffer sensor B41
Flue gas temp sensor B8
Common flow sensor B10
Solid fuel boiler sensor B22
DHW charging sensor B36
Buffer sensor B42
Common return sensor B73
Cascade return sensor B70
Swimming pool sensor B13
Solar flow sensor B63
Solar return sensor B64
DHW outlet sensor B38
Primary exch sensor B26
Boiler sensor B2
Solar sensor ext exch B62
DHW sensor B3
Outside sensor B9
Primary contr sensor B15
Room sensor B5
Room sensor B52
Room sensor B53
Flow sensor HC1 B1
Flow sensor HC2 B12
Flow sensor HC3 B14
Temp diff on dT contr 1,
2
On temp min dT contr
1, 2
Sensor 1 dT controller
1, 2
