Building Technologies Division User Manual LMS14… CC1U7471en
6 The settings in detail 28.01.2015
Line no. Operating line
Controller 1 Controller 2
5574 5584 Sensor 2 dT controller 1, 2
None
DHW sensor B31
Collector sensor B6
Return sensor B7
DHW circulation sensor B39
Buffer sensor B4
Buffer sensor B41
Flue gas temp sensor B8
Common flow sensor B10
Solid fuel boiler sensor B22
DHW charging sensor B36
Buffer sensor B42
Common return sensor B73
Cascade return sensor B70
Swimming pool sensor B13
Solar flow sensor B63
Solar return sensor B64
DHW outlet sensor B38
Primary exch sensor B26
Boiler sensor B2
Solar sensor ext exch B62
DHW sensor B3
Outside sensor B9
Primary contr sensor B15
Room sensor B5
Room sensor B52
Room sensor B53
Flow sensor HC1 B1
Flow sensor HC2 B12
Flow sensor HC3 B14
None
Sensor input has no function.
DHW sensor B31
Lower DHW storage tank sensor.
Collector sensor B6
This sensor is required for the solar function.
DHW circulation sensor B39
DHW circulation sensor/standby sensor.
Buffer sensor B4
Upper buffer sensor.
Buffer sensor B41
Lower buffer sensor.
Flue gas temp sensor B8
This sensor is required for flue gas supervision.
Common flow sensor B10
This sensor is required for the common flow.
Sensor 2 dT controller
1, 2
