Building Technologies Division User Manual LMS14… CC1U7471en
6 The settings in detail 28.01.2015
Line no. Operating line
2325 Speed Tn
2326 Speed Tv
2329 Pump setpoint reduction
2330 Output nominal
2331 Output basic stage
2334 Output at pump speed min
2335 Output at pump speed max
2441 Fan speed heating max
2442 Fan speed full charging max
2444 Fan speed DHW max
2445 Fan shutdown heating mode
Off ¦ On
2446 Fan shutdown delay
2450 Controller delay
Off ¦ Heating mode only ¦ DHW mode only ¦ Heating and DHW mode
2452 Controller delay speed
2453 Controller delay duration
2454 Switching diff on HCs
2455 Switching diff off min HCs
2456 Switching diff off max HCs
2457 Settling time HCs
2460 Switching diff on DHW
2461 Switching diff off min DHW
2462 Switching diff off max DHW
2463 Settling time DHW
2470 Delay heat req special op
2511 Quick shutdown superv time
2512 Quick shutdown superv RT
Off ¦ On
2630 Auto deaeration procedure
Off ¦ On
2655 ON time deaeration
2656 OFF time deaeration
2657 Number of repetitions
2662 Deaeration time heat circuit
2663 Deaeration time DHW
Cascade
3510 Lead strategy
Late on, early off ¦ Late on, late off ¦ Early on, late off
3511 Output band min
3512 Output band max
3530 Release integral source seq
3531 Reset integral source seq
3532 Restart lock
3533 Switch on delay
3541 Auto source seq excluding
3544 Leading source
Source 1 ¦ Source 2 ¦ Source 3 ¦ Source 4 ¦ Source 5 ¦ Source 6 ¦ Source 7 ¦ Source 8 ¦ Source 9 ¦ Source 10 ¦ Source 11 ¦
Source 12 ¦ Source 13 ¦ Source 14 ¦ Source 15 ¦ Source 16
3560 Return setpoint min
3562 Return influence consumers
Off ¦ On
3590 Temp differential min
