6 The settings in detail 28.01.2015
Line no. Operating line
2055 Setpoint solar heating
2056 Setpoint source heating
2065 Charging priority solar
Priority 1 ¦ Priority 2 ¦ Priority 3
2070 Swimming pool temp max
2080 With solar integration
No ¦ Yes
Primary controller/system pump
2110 Flow temp setpoint min
2111 Flow temp setpoint max
2121 Syst pump on heat gen lock
Off ¦ On
2130 Mixing valve boost
2132 Actuator type
2-position ¦ 3-position
2133 Switching differential 2-pos
2134 Actuator running time
2135 Mixing valve Xp
2136 Mixing valve Tn
2150 Primary contr/system pump
Before buffer ¦ After buffer
Boiler
2203 Release below outside temp
2208 Full charging buffer
Off ¦ On
2210 Setpoint min
2212 Setpoint max
2233 P-band Xp HCs
2234 Int action time Tn HCs
2235 Der action time Tv HCs
2236 P-band Xp DHW
2237 Int action time Tn DHW
2238 Der action time Tv DHW
2241 Burner running time min
2243 Burner off time min
2245 SD burner off time
2250 Pump overrun time
2253 Pump overr time after DHW
2270 Return setpoint min
2300 FrostPlnt boiler pump
Off ¦ On
2301 Boiler pump on heat gen lock
Off ¦ On
2305 Impact heat generation lock
Heating mode only ¦ Heating and DHW mode
2316 Temp differential max
2317 Temp differential nominal
2320 Pump modulation
None ¦ Demand ¦ Boiler setpoint ¦ Temp differential nominal ¦ Burner output
2321 Starting speed
2322 Pump speed min
2323 Pump speed max
2324 Speed Xp
