455/617
Building Technologies Division User Manual LMS14… CC1U7471en
6 The settings in detail 28.01.2015
Line no.
Operating line
None | DHW sensor B31 | Collector sensor B6 | Return sensor B7 | DHW circulation sensor B39 | Buffer sensor B4 | Buffer
sensor B41 | Flue gas temp sensor B8 | Common flow sensor B10 | Solid fuel boiler sensor B22 | DHW charging sensor B36 |
Buffer sensor B42 | Common return sensor B73 | Cascade return sensor B70 | Swimming pool sensor B13 | Solar flow sensor
B63 | Solar return sensor B64 | DHW outlet sensor B38 | Primary exch sensor B26 | Boiler sensor B2 | Solar sensor ext exch
B62 | DHW sensor B3 | Outside sensor B9 | Primary contr sensor B15 | Room sensor B5 | Room sensor B52 | Room sensor B53
| Flow sensor HC1 B1 | Flow sensor HC2 B12 | Flow sensor HC3 B14
5574
Sensor 2 dT controller 1
None | DHW sensor B31 | Collector sensor B6 | Return sensor B7 | DHW circulation sensor B39 | Buffer sensor B4 | Buffer
sensor B41 | Flue gas temp sensor B8 | Common flow sensor B10 | Solid fuel boiler sensor B22 | DHW charging sensor B36 |
Buffer sensor B42 | Common return sensor B73 | Cascade return sensor B70 | Swimming pool sensor B13 | Solar flow sensor
B63 | Solar return sensor B64 | DHW outlet sensor B38 | Primary exch sensor B26 | Boiler sensor B2 | Solar sensor ext exch
B62 | DHW sensor B3 | Outside sensor B9 | Primary contr sensor B15 | Room sensor B5 | Room sensor B52 | Room sensor B53
| Flow sensor HC1 B1 | Flow sensor HC2 B12 | Flow sensor HC3 B14
5575 On time min dT contr 1
5577
Pump/valve kick K21
Off | On
5580 Temp diff on dT contr 2
5581 Temp diff off dT contr 2
5582 On temp min dT contr 2
5583
Sensor 1 dT controller 2
None | DHW sensor B31 | Collector sensor B6 | Return sensor B7 | DHW circulation sensor B39 | Buffer sensor B4 | Buffer
sensor B41 | Flue gas temp sensor B8 | Common flow sensor B10 | Solid fuel boiler sensor B22 | DHW charging sensor B36 |
Buffer sensor B42 | Common return sensor B73 | Cascade return sensor B70 | Swimming pool sensor B13 | Solar flow sensor
B63 | Solar return sensor B64 | DHW outlet sensor B38 | Primary exch sensor B26 | Boiler sensor B2 | Solar sensor ext exch
B62 | DHW sensor B3 | Outside sensor B9 | Primary contr sensor B15 | Room sensor B5 | Room sensor B52 | Room sensor B53
| Flow sensor HC1 B1 | Flow sensor HC2 B12 | Flow sensor HC3 B14
5584
Sensor 2 dT controller 2
None | DHW sensor B31 | Collector sensor B6 | Return sensor B7 | DHW circulation sensor B39 | Buffer sensor B4 | Buffer
sensor B41 | Flue gas temp sensor B8 | Common flow sensor B10 | Solid fuel boiler sensor B22 | DHW charging sensor B36 |
Buffer sensor B42 | Common return sensor B73 | Cascade return sensor B70 | Swimming pool sensor B13 | Solar flow sensor
B63 | Solar return sensor B64 | DHW outlet sensor B38 | Primary exch sensor B26 | Boiler sensor B2 | Solar sensor ext exch
B62 | DHW sensor B3 | Outside sensor B9 | Primary contr sensor B15 | Room sensor B5 | Room sensor B52 | Room sensor B53
| Flow sensor HC1 B1 | Flow sensor HC2 B12 | Flow sensor HC3 B14
5585 On time min dT contr 2
5587
Pump/valve kick K22
Off | On
Configuration
5710 Heating circuit 1
Off ¦ On
5711 Cooling circuit 1
Off ¦ 4-pipe system cooling
5715 Heating circuit 2
Off ¦ On
5721 Heating circuit 3
Off ¦ On
5730 DHW sensor
DHW sensor B3 ¦ Thermostat | DHW outlet sensor B38
5731 DHW controlling element
None ¦ Charging pump ¦ Diverting valve
5732 Pump off change div valve
5733 Delay pump off
5734 Basic position DHW div valve
Last request ¦ Heating circuit ¦ DHW
5736 DHW separate circuit
