Siemens LMS14

456/617
Building Technologies Division User Manual LMS14… CC1U7471en
6 The settings in detail 28.01.2015
Line no. Operating line
Off ¦ On
5737 Optg action DHW div valve
Position on DHW ¦ Position on heating circuit
5774 Ctrl boiler pump/DHW valve
All requests ¦ Request HC1/DHW only
5775 Boiler pump with DHW
On ¦ Off
5840 Solar controlling element
Charging pump ¦ Diverting valve
5841 External solar exchanger
Jointly ¦ DHW storage tank ¦ Buffer storage tank
5870 Combi storage tank
Yes ¦ No
5890 Relay output QX1
None ¦ Circulating pump Q4 ¦ El imm heater DHW K6 ¦ Collector pump Q5 ¦ Cons circuit pump VK1 Q15 ¦ Boiler pump Q1 ¦
Bypass pump Q12 ¦ Alarm output K10 ¦ 2nd pump speed HC1 Q21 ¦ 2nd pump speed HC2 Q22 ¦ 2nd pump speed HC3 Q23 ¦
Heat circuit pump HC3 Q20 ¦ Cons circuit pump VK2 Q18 ¦ System pump Q14 ¦ Heat gen shutoff valve Y4 ¦ Solid fuel boiler pump
Q10 ¦ Time program 5 K13 ¦ Buffer return valve Y15 ¦ Solar pump ext exch K9 ¦ Solar ctrl elem buffer K8 ¦ Solar ctrl elem swi pool
K18 ¦ Swimming pool pump Q19 ¦ Cascade pump Q25 ¦ St tank transfer pump Q11 ¦ DHW mixing pump Q35 ¦ DHW interm circ
pump Q33 ¦ Heat request K27 ¦ Refrigeration request K28 ¦ Heat circuit pump HC1 Q2 ¦ Heat circuit pump HC2 Q6 ¦ DHW ctrl
elem Q3 ¦ Instant WH ctrl elem Q34 ¦ Water refill K34 ¦ 2nd boiler pump speed Q27 ¦ Status output K35 ¦ Status information K36 ¦
Flue gas damper K37 ¦ Fan shutdown K38 ¦ dT controller 1 K21 ¦ dT controller 2 K22
5891 Relay output QX2
None ¦ Circulating pump Q4 ¦ El imm heater DHW K6 ¦ Collector pump Q5 ¦ Cons circuit pump VK1 Q15 ¦ Boiler pump Q1 ¦
Bypass pump Q12 ¦ Alarm output K10 ¦ 2nd pump speed HC1 Q21 ¦ 2nd pump speed HC2 Q22 ¦ 2nd pump speed HC3 Q23 ¦
Heat circuit pump HC3 Q20 ¦ Cons circuit pump VK2 Q18 ¦ System pump Q14 ¦ Heat gen shutoff valve Y4 ¦ Solid fuel boiler pump
Q10 ¦ Time program 5 K13 ¦ Buffer return valve Y15 ¦ Solar pump ext exch K9 ¦ Solar ctrl elem buffer K8 ¦ Solar ctrl elem swi pool
K18 ¦ Swimming pool pump Q19 ¦ Cascade pump Q25 ¦ St tank transfer pump Q11 ¦ DHW mixing pump Q35 ¦ DHW interm circ
pump Q33 ¦ Heat request K27 ¦ Refrigeration request K28 ¦ Heat circuit pump HC1 Q2 ¦ Heat circuit pump HC2 Q6 ¦ DHW ctrl
elem Q3 ¦ Instant WH ctrl elem Q34 ¦ Water refill K34 ¦ 2nd boiler pump speed Q27 ¦ Status output K35 ¦ Status information K36 ¦
Flue gas damper K37 ¦ Fan shutdown K38 ¦ dT controller 1 K21 ¦ dT controller 2 K22
5892 Relay output QX3
None ¦ Circulating pump Q4 ¦ El imm heater DHW K6 ¦ Collector pump Q5 ¦ Cons circuit pump VK1 Q15 ¦ Boiler pump Q1 ¦
Bypass pump Q12 ¦ Alarm output K10 ¦ 2nd pump speed HC1 Q21 ¦ 2nd pump speed HC2 Q22 ¦ 2nd pump speed HC3 Q23 ¦
Heat circuit pump HC3 Q20 ¦ Cons circuit pump VK2 Q18 ¦ System pump Q14 ¦ Heat gen shutoff valve Y4 ¦ Solid fuel boiler pump
Q10 ¦ Time program 5 K13 ¦ Buffer return valve Y15 ¦ Solar pump ext exch K9 ¦ Solar ctrl elem buffer K8 ¦ Solar ctrl elem swi pool
K18 ¦ Swimming pool pump Q19 ¦ Cascade pump Q25 ¦ St tank transfer pump Q11 ¦ DHW mixing pump Q35 ¦ DHW interm circ
pump Q33 ¦ Heat request K27 ¦ Refrigeration request K28 ¦ Heat circuit pump HC1 Q2 ¦ Heat circuit pump HC2 Q6 ¦ DHW ctrl
elem Q3 ¦ Instant WH ctrl elem Q34 ¦ Water refill K34 ¦ 2nd boiler pump speed Q27 ¦ Status output K35 ¦ Status information K36 ¦
Flue gas damper K37 ¦ Fan shutdown K38 ¦ dT controller 1 K21 ¦ dT controller 2 K22
5894 Relay output QX4
None ¦ Heat gen shutoff valve Y4 ¦ Buffer return valve Y15 ¦ Solar ctrl elem buffer K8 ¦ Solar ctrl elem swi pool K18 ¦ DHW ctrl
elem Q3
¦ Instant WH ctrl elem Q34
5930 Sensor input BX1
None ¦ DHW sensor B31 ¦ Collector sensor B6 ¦ DHW circulation sensor B39 ¦ Buffer sensor B4 ¦ Buffer sensor B41 ¦ Flue gas
temp sensor B8 ¦ Common flow sensor B10 ¦ Solid fuel boiler sensor B22 ¦ DHW charging sensor B36 ¦ Buffer sensor B42 ¦
Common return sensor B73 ¦ Cascade return sensor B70 ¦ Swimming pool sensor B13 ¦ Solar flow sensor B63 ¦ Solar return
sensor B64 ¦ Primary exch sensor B26
5931 Sensor input BX2
None ¦ DHW sensor B31 ¦ Collector sensor B6 ¦ DHW circulation sensor B39 ¦ Buffer sensor B4 ¦ Buffer sensor B41 ¦ Flue gas
temp sensor B8 ¦ Common flow sensor B10 ¦ Solid fuel boiler sensor B22 ¦ DHW charging sensor B36 ¦ Buffer sensor B42 ¦
Common return sensor B73 ¦ Cascade return sensor B70 ¦ Swimming pool sensor B13 ¦ Solar flow sensor B63 ¦ Solar return
sensor B64 ¦ Primary exch sensor B26
5932 Sensor input BX3
