Siemens LMS14

458/617
Building Technologies Division User Manual LMS14… CC1U7471en
6 The settings in detail 28.01.2015
Line no. Operating line
6008 Function input H6
None ¦ Optg mode change HCs+DHW ¦ Optg mode changeover DHW ¦ Optg mode changeover HCs ¦ Optg mode changeover
HC1 ¦ Optg mode changeover HC2 ¦ Optg mode changeover HC3 ¦ Heat generation lock ¦ Error/alarm message ¦ Consumer
request VK1 ¦ Consumer request VK2 ¦ Release swi pool source heat ¦ Excess heat discharge ¦ Release swi pool solar ¦
Operating level DHW ¦ Operating level HC1 ¦ Operating level HC2 ¦ Operating level HC3 ¦ Room thermostat HC1 ¦ Room
thermostat HC2 ¦ Room thermostat HC3 ¦ DHW flow switch ¦ DHW thermostat ¦ Pulse count ¦ Checkb sign flue gas damper ¦ Start
prevention ¦ Boiler flow switch ¦ Boiler pressure switch ¦ Gas pressure switch
6009 Contact type H6
NC ¦ NO
6011 Function input H7
None ¦ Optg mode change HCs+DHW ¦ Optg mode changeover DHW ¦ Optg mode changeover HCs ¦ Optg mode changeover
HC1 ¦ Optg mode changeover HC2 ¦ Optg mode changeover HC3 ¦ Heat generation lock ¦ Error/alarm message ¦ Consumer
request VK1 ¦ Consumer request VK2 ¦ Release swi pool source heat ¦ Excess heat discharge ¦ Release swi pool solar ¦
Operating level DHW ¦ Operating level HC1 ¦ Operating level HC2 ¦ Operating level HC3 ¦ Room thermostat HC1 ¦ Room
thermostat HC2 ¦ Room thermostat HC3 ¦ DHW flow switch ¦ DHW thermostat ¦ Pulse count ¦ Checkb sign flue gas damper ¦ Start
prevention ¦ Boiler flow switch ¦ Boiler pressure switch
6012 Contact type H7
NC ¦ NO
6020 Function extension module 1
None ¦ Multifunctional ¦ Heating circuit 1 ¦ Heating circuit 2 ¦ Heating circuit 3 ¦ Return temp controller ¦ Solar DHW ¦ Primary
contr/system pump
6021 Function extension module 2
None ¦ Multifunctional ¦ Heating circuit 1 ¦ Heating circuit 2 ¦ Heating circuit 3 ¦ Return temp controller ¦ Solar DHW ¦ Primary
contr/system pump
6022 Function extension module 3
None ¦ Multifunctional ¦ Heating circuit 1 ¦ Heating circuit 2 ¦ Heating circuit 3 ¦ Return temp controller ¦ Solar DHW ¦ Primary
contr/system pump
6024 Funct input EX21 module 1
None ¦ Limit thermostat HC
6026 Funct input EX21 module 2
None ¦ Limit thermostat HC
6028 Funct input EX21 module 3
None ¦ Limit thermostat HC
6030 Relay output QX21 module 1
None ¦ Circulating pump Q4 ¦ El imm heater DHW K6 ¦ Collector pump Q5 ¦ Cons circuit pump VK1 Q15 ¦ Boiler pump Q1 ¦
Bypass pump Q12 ¦ Alarm output K10 ¦ 2nd pump speed HC1 Q21 ¦ 2nd pump speed HC2 Q22 ¦ 2nd pump speed HC3 Q23 ¦
Heat circuit pump HC3 Q20 ¦ Cons circuit pump VK2 Q18 ¦ System pump Q14 ¦ Heat gen shutoff valve Y4 ¦ Solid fuel boiler pump
Q10 ¦ Time program 5 K13 ¦ Buffer return valve Y15 ¦ Solar pump ext exch K9 ¦ Solar ctrl elem buffer K8 ¦ Solar ctrl elem swi pool
K18 ¦ Swimming pool pump Q19 ¦ Cascade pump Q25 ¦ St tank transfer pump Q11 ¦ DHW mixing pump Q35 ¦ DHW interm circ
pump Q33 ¦ Heat request K27 ¦ Refrigeration request K28 ¦ Heat circuit pump HC1 Q2 ¦ Heat circuit pump HC2 Q6 ¦ DHW ctrl
elem Q3 ¦ Instant WH ctrl elem Q34 ¦ Water refill K34 ¦ 2nd boiler pump speed Q27 ¦ Status output K35 ¦ Status information K36 ¦
Fan shutdown K38 ¦ dT controller 1 K21 ¦ dT controller 2 K22
6031 Relay output QX22 module 1
None ¦ Circulating pump Q4 ¦ El imm heater DHW K6 ¦ Collector pump Q5 ¦ Cons circuit pump VK1 Q15 ¦ Boiler pump Q1 ¦
Bypass pump Q12 ¦ Alarm output K10 ¦ 2nd pump speed HC1 Q21 ¦ 2nd pump speed HC2 Q22 ¦ 2nd pump speed HC3 Q23 ¦
Heat circuit pump HC3 Q20 ¦ Cons circuit pump VK2 Q18 ¦ System pump Q14 ¦ Heat gen shutoff valve Y4 ¦ Solid fuel boiler pump
Q10 ¦ Time program 5 K13 ¦ Buffer return valve Y15 ¦ Solar pump ext exch K9 ¦ Solar ctrl elem buffer K8 ¦ Solar ctrl elem swi pool
K18 ¦ Swimming pool pump Q19 ¦ Cascade pump Q25 ¦ St tank transfer pump Q11 ¦ DHW mixing pump Q35 ¦ DHW interm circ
pump Q33 ¦ Heat request K27 ¦ Refrigeration request K28 ¦ Heat circuit pump HC1 Q2 ¦ Heat circuit pump HC2 Q6 ¦ DHW ctrl
elem Q3 ¦ Instant WH ctrl elem Q34 ¦ Water refill K34 ¦ 2nd boiler pump speed Q27 ¦ Status output K35 ¦ Status information K36 ¦
Fan shutdown K38 ¦ dT controller 1 K21 ¦ dT controller 2 K22
6032 Relay output QX23 module 1
None ¦ Circulating pump Q4 ¦ El imm heater DHW K6 ¦ Collector pump Q5 ¦ Cons circuit pump VK1 Q15 ¦ Boiler pump Q1 ¦
Bypass pump Q12 ¦ Alarm output K10 ¦ 2nd pump speed HC1 Q21 ¦ 2nd pump speed HC2 Q22 ¦ 2nd pump speed HC3 Q23 ¦
