Building Technologies Division User Manual LMS14… CC1U7471en
6 The settings in detail 28.01.2015
Line no.
Operating line
Heat circuit pump HC3 Q20 ¦ Cons circuit pump VK2 Q18 ¦ System pump Q14 ¦ Heat gen shutoff valve Y4 ¦ Solid fuel boiler pump
Q10 ¦ Time program 5 K13 ¦ Buffer return valve Y15 ¦ Solar pump ext exch K9 ¦ Solar ctrl elem buffer K8 ¦ Solar ctrl elem swi pool
K18 ¦ Swimming pool pump Q19 ¦ Cascade pump Q25 ¦ St tank transfer pump Q11 ¦ DHW mixing pump Q35 ¦ DHW interm circ
pump Q33 ¦ Heat request K27 ¦ Refrigeration request K28 ¦ Heat circuit pump HC1 Q2 ¦ Heat circuit pump HC2 Q6 ¦ DHW ctrl
elem Q3 ¦ Instant WH ctrl elem Q34 ¦ Water refill K34 ¦ 2nd boiler pump speed Q27 ¦ Status output K35 ¦ Status information K36 ¦
Fan shutdown K38¦ dT controller 1 K21 ¦ dT controller 2 K22
6033 Relay output QX21 module 2
None ¦ Circulating pump Q4 ¦ El imm heater DHW K6 ¦ Collector pump Q5 ¦ Cons circuit pump VK1 Q15 ¦ Boiler pump Q1 ¦
Bypass pump Q12 ¦ Alarm output K10 ¦ 2nd pump speed HC1 Q21 ¦ 2nd pump speed HC2 Q22 ¦ 2nd pump speed HC3 Q23 ¦
Heat circuit pump HC3 Q20 ¦ Cons circuit pump VK2 Q18 ¦ System pump Q14 ¦ Heat gen shutoff valve Y4 ¦ Solid fuel boiler pump
Q10 ¦ Time program 5 K13 ¦ Buffer return valve Y15 ¦ Solar pump ext exch K9 ¦ Solar ctrl elem buffer K8 ¦ Solar ctrl elem swi pool
K18 ¦ Swimming pool pump Q19 ¦ Cascade pump Q25 ¦ St tank transfer pump Q11 ¦ DHW mixing pump Q35 ¦ DHW interm circ
pump Q33 ¦ Heat request K27 ¦ Refrigeration request K28 ¦ Heat circuit pump HC1 Q2 ¦ Heat circuit pump HC2 Q6 ¦ DHW ctrl
elem Q3 ¦ Instant WH ctrl elem Q34 ¦ Water refill K34 ¦ 2nd boiler pump speed Q27 ¦ Status output K35 ¦ Status information K36 ¦
Fan shutdown K38¦ dT controller 1 K21 ¦ dT controller 2 K22
6034 Relay output QX22 module 2
None ¦ Circulating pump Q4 ¦ El imm heater DHW K6 ¦ Collector pump Q5 ¦ Cons circuit pump VK1 Q15 ¦ Boiler pump Q1 ¦
Bypass pump Q12 ¦ Alarm output K10 ¦ 2nd pump speed HC1 Q21 ¦ 2nd pump speed HC2 Q22 ¦ 2nd pump speed HC3 Q23 ¦
Heat circuit pump HC3 Q20 ¦ Cons circuit pump VK2 Q18 ¦ System pump Q14 ¦ Heat gen shutoff valve Y4 ¦ Solid fuel boiler pump
Q10 ¦ Time program 5 K13 ¦ Buffer return valve Y15 ¦ Solar pump ext exch K9 ¦ Solar ctrl elem buffer K8 ¦ Solar ctrl elem swi pool
K18 ¦ Swimming pool pump Q19 ¦ Cascade pump Q25 ¦ St tank transfer pump Q11 ¦ DHW mixing pump Q35 ¦ DHW interm circ
pump Q33 ¦ Heat request K27 ¦ Refrigeration request K28 ¦ Heat circuit pump HC1 Q2 ¦ Heat circuit pump HC2 Q6 ¦ DHW ctrl
elem Q3 ¦ Instant WH ctrl elem Q34 ¦ Water refill K34 ¦ 2nd boiler pump speed Q27 ¦ Status output K35 ¦ Status information K36 ¦
Fan shutdown K38 ¦ dT controller 1 K21 ¦ dT controller 2 K22
6035 Relay output QX23 module 2
None ¦ Circulating pump Q4 ¦ El imm heater DHW K6 ¦ Collector pump Q5 ¦ Cons circuit pump VK1 Q15 ¦ Boiler pump Q1 ¦
Bypass pump Q12 ¦ Alarm output K10 ¦ 2nd pump speed HC1 Q21 ¦ 2nd pump speed HC2 Q22 ¦ 2nd pump speed HC3 Q23 ¦
Heat circuit pump HC3 Q20 ¦ Cons circuit pump VK2 Q18 ¦ System pump Q14 ¦ Heat gen shutoff valve Y4 ¦ Solid fuel boiler pump
Q10 ¦ Time program 5 K13 ¦ Buffer return valve Y15 ¦ Solar pump ext exch K9 ¦ Solar ctrl elem buffer K8 ¦ Solar ctrl elem swi pool
K18 ¦ Swimming pool pump Q19 ¦ Cascade pump Q25 ¦ St tank transfer pump Q11 ¦ DHW mixing pump Q35 ¦ DHW interm circ
pump Q33 ¦ Heat request K27 ¦ Refrigeration request K28 ¦ Heat circuit pump HC1 Q2 ¦ Heat circuit pump HC2 Q6 ¦ DHW ctrl
elem Q3 ¦ Instant WH ctrl elem Q34 ¦ Water refill K34 ¦ 2nd boiler pump speed Q27 ¦ Status output K35 ¦ Status information K36 ¦
Fan shutdown K38 ¦ dT controller 1 K21 ¦ dT controller 2 K22
6036 Relay output QX21 module 3
None ¦ Circulating pump Q4 ¦ El imm heater DHW K6 ¦ Collector pump Q5 ¦ Cons circuit pump VK1 Q15 ¦ Boiler pump Q1 ¦
Bypass pump Q12 ¦ Alarm output K10 ¦ 2nd pump speed HC1 Q21 ¦ 2nd pump speed HC2 Q22 ¦ 2nd pump speed HC3 Q23 ¦
Heat circuit pump HC3 Q20 ¦ Cons circuit pump VK2 Q18 ¦ System pump Q14 ¦ Heat gen shutoff valve Y4 ¦ Solid fuel boiler pump
Q10 ¦ Time program 5 K13 ¦ Buffer return valve Y15 ¦ Solar pump ext exch K9 ¦ Solar ctrl elem buffer K8 ¦ Solar ctrl elem swi pool
K18 ¦ Swimming pool pump Q19 ¦ Cascade pump Q25 ¦ St tank transfer pump Q11 ¦ DHW mixing pump Q35 ¦ DHW interm circ
pump Q33 ¦ Heat request K27 ¦ Refrigeration request K28 ¦ Heat circuit pump HC1 Q2 ¦ Heat circuit pump HC2 Q6 ¦ DHW ctrl
elem Q3 ¦ Instant WH ctrl elem Q34 ¦ Water refill K34 ¦ 2nd boiler pump speed Q27 ¦ Status output K35 ¦ Status information K36 ¦
Fan shutdown K38¦ dT controller 1 K21 ¦ dT controller 2 K22
6037 Relay output QX22 module 3
None ¦ Circulating pump Q4 ¦ El imm heater DHW K6 ¦ Collector pump Q5 ¦ Cons circuit pump VK1 Q15 ¦ Boiler pump Q1 ¦
Bypass pump Q12 ¦ Alarm output K10 ¦ 2nd pump speed HC1 Q21 ¦ 2nd pump speed HC2 Q22 ¦ 2nd pump speed HC3 Q23 ¦
Heat circuit pump HC3 Q20 ¦ Cons circuit pump VK2 Q18 ¦ System pump Q14 ¦ Heat gen shutoff valve Y4 ¦ Solid fuel boiler pump
Q10 ¦ Time program 5 K13 ¦ Buffer return valve Y15 ¦ Solar pump ext exch K9 ¦ Solar ctrl elem buffer K8 ¦ Solar ctrl elem swi pool
K18 ¦ Swimming pool pump Q19 ¦ Cascade pump Q25 ¦ St tank transfer pump Q11 ¦ DHW mixing pump Q35 ¦ DHW interm circ
pump Q33 ¦ Heat request K27 ¦ Refrigeration request K28 ¦ Heat circuit pump HC1 Q2 ¦ Heat circuit pump HC2 Q6 ¦ DHW ctrl
elem Q3 ¦ Instant WH ctrl elem Q34 ¦ Water refill K34 ¦ 2nd boiler pump speed Q27 ¦ Status output K35 ¦ Status information K36 ¦
Fan shutdown K38 ¦ dT controller 1 K21 ¦ dT controller 2 K22
6038 Relay output QX23 module 3
None ¦ Circulating pump Q4 ¦ El imm heater DHW K6 ¦ Collector pump Q5 ¦ Cons circuit pump VK1 Q15 ¦ Boiler pump Q1 ¦
Bypass pump Q12 ¦ Alarm output K10 ¦ 2nd pump speed HC1 Q21 ¦ 2nd pump speed HC2 Q22 ¦ 2nd pump speed HC3 Q23 ¦
Heat circuit pump HC3 Q20 ¦ Cons circuit pump VK2 Q18 ¦ System pump Q14 ¦ Heat gen shutoff valve Y4 ¦ Solid fuel boiler pump
