Siemens LMS14

460/617
Building Technologies Division User Manual LMS14… CC1U7471en
6 The settings in detail 28.01.2015
Line no. Operating line
Q10 ¦ Time program 5 K13 ¦ Buffer return valve Y15 ¦ Solar pump ext exch K9 ¦ Solar ctrl elem buffer K8 ¦ Solar ctrl elem swi pool
K18 ¦ Swimming pool pump Q19 ¦ Cascade pump Q25 ¦ St tank transfer pump Q11 ¦ DHW mixing pump Q35 ¦ DHW interm circ
pump Q33 ¦ Heat request K27 ¦ Refrigeration request K28 ¦ Heat circuit pump HC1 Q2 ¦ Heat circuit pump HC2 Q6 ¦ DHW ctrl
elem Q3 ¦ Instant WH ctrl elem Q34 ¦ Water refill K34 ¦ 2nd boiler pump speed Q27 ¦ Status output K35 ¦ Status information K36 ¦
Flue gas damper K37 ¦ Fan shutdown K38 ¦ dT controller 1 K21 ¦ dT controller 2 K22
6040 Sensor input BX21 module 1
None ¦ DHW sensor B31 ¦ Collector sensor B6 ¦ DHW circulation sensor B39 ¦ Buffer sensor B4 ¦ Buffer sensor B41 ¦ Flue gas
temp sensor B8 ¦ Common flow sensor B10 ¦ Solid fuel boiler sensor B22 ¦ DHW charging sensor B36 ¦ Buffer sensor B42 ¦
Common return sensor B73 ¦ Cascade return sensor B70 ¦ Swimming pool sensor B13 ¦ Solar flow sensor B63 ¦ Solar return
sensor B64 ¦ Primary exch sensor B26
6041 Sensor input BX22 module 1
None ¦ DHW sensor B31 ¦ Collector sensor B6 ¦ DHW circulation sensor B39 ¦ Buffer sensor B4 ¦ Buffer sensor B41 ¦ Flue gas
temp sensor B8 ¦ Common flow sensor B10 ¦ Solid fuel boiler sensor B22 ¦ DHW charging sensor B36 ¦ Buffer sensor B42 ¦
Common return sensor B73 ¦ Cascade return sensor B70 ¦ Swimming pool sensor B13 ¦ Solar flow sensor B63 ¦ Solar return
sensor B64 ¦ Primary exch sensor B26
6042 Sensor input BX21 module 2
None ¦ DHW sensor B31 ¦ Collector sensor B6 ¦ DHW circulation sensor B39 ¦ Buffer sensor B4 ¦ Buffer sensor B41 ¦ Flue gas
temp sensor B8 ¦ Common flow sensor B10 ¦ Solid fuel boiler sensor B22 ¦ DHW charging sensor B36 ¦ Buffer sensor B42 ¦
Common return sensor B73 ¦ Cascade return sensor B70 ¦ Swimming pool sensor B13 ¦ Solar flow sensor B63 ¦ Solar return
sensor B64 ¦ Primary exch sensor B26
6043 Sensor input BX22 module 2
None ¦ DHW sensor B31 ¦ Collector sensor B6 ¦ DHW circulation sensor B39 ¦ Buffer sensor B4 ¦ Buffer sensor B41 ¦ Flue gas
temp sensor B8 ¦ Common flow sensor B10 ¦ Solid fuel boiler sensor B22 ¦ DHW charging sensor B36 ¦ Buffer sensor B42 ¦
Common return sensor B73 ¦ Cascade return sensor B70 ¦ Swimming pool sensor B13 ¦ Solar flow sensor B63 ¦ Solar return
sensor B64 ¦ Primary exch sensor B26
6044 Sensor input BX21 module 3
None ¦ DHW sensor B31 ¦ Collector sensor B6 ¦ DHW circulation sensor B39 ¦ Buffer sensor B4 ¦ Buffer sensor B41 ¦ Flue gas
temp sensor B8 ¦ Common flow sensor B10 ¦ Solid fuel boiler sensor B22 ¦ DHW charging sensor B36 ¦ Buffer sensor B42 ¦
Common return sensor B73 ¦ Cascade return sensor B70 ¦ Swimming pool sensor B13 ¦ Solar flow sensor B63 ¦ Solar return
sensor B64 ¦ Primary exch sensor B26
6045 Sensor input BX22 module 3
None ¦ DHW sensor B31 ¦ Collector sensor B6 ¦ DHW circulation sensor B39 ¦ Buffer sensor B4 ¦ Buffer sensor B41 ¦ Flue gas
temp sensor B8 ¦ Common flow sensor B10 ¦ Solid fuel boiler sensor B22 ¦ DHW charging sensor B36 ¦ Buffer sensor B42 ¦
Common return sensor B73 ¦ Cascade return sensor B70 ¦ Swimming pool sensor B13 ¦ Solar flow sensor B63 ¦ Solar return
sensor B64 ¦ Primary exch sensor B26
6046 Function input H2 module 1
None ¦ Optg mode change HCs+DHW ¦ Optg mode changeover DHW ¦ Optg mode changeover HCs ¦ Optg mode changeover
HC1 ¦ Optg mode changeover HC2 ¦ Optg mode changeover HC3 ¦ Heat generation lock ¦ Error/alarm message ¦ Consumer
request VK1 ¦ Consumer request VK2 ¦ Release swi pool source heat ¦ Excess heat discharge ¦ Release swi pool solar ¦
Operating level DHW ¦ Operating level HC1 ¦ Operating level HC2 ¦ Operating level HC3 ¦ Room thermostat HC1 ¦ Room
thermostat HC2 ¦ Room thermostat HC3 ¦ DHW flow switch ¦ DHW thermostat ¦ Limit thermostat HC ¦ Start prevention ¦ Boiler flow
switch ¦ Boiler pressure switch ¦ Consumer request VK1 10V ¦ Consumer request VK2 10V ¦ Pressure measurement 10V ¦ Output
request 10V
6047 Contact type H2 module 1
NC ¦ NO
6049 Voltage value 1 H2 module 1
6050 Function value 1 H2 module 1
6051 Voltage value 2 H2 module 1
6052 Function value 2 H2 module 1
6054 Function input H2 module 2
None ¦ Optg mode change HCs+DHW ¦ Optg mode changeover DHW ¦ Optg mode changeover HCs ¦ Optg mode changeover
HC1 ¦ Optg mode changeover HC2 ¦ Optg mode changeover HC3 ¦ Heat generation lock ¦ Error/alarm message ¦ Consumer
request VK1 ¦ Consumer request VK2 ¦ Release swi pool source heat ¦ Excess heat discharge ¦ Release swi pool solar ¦
Operating level DHW ¦ Operating level HC1 ¦ Operating level HC2 ¦ Operating level HC3 ¦ Room thermostat HC1 ¦ Room
