Building Technologies Division User Manual LMS14… CC1U7471en
6 The settings in detail 28.01.2015
Line no.
Operating line
thermostat HC2 ¦ Room thermostat HC3 ¦ DHW flow switch ¦ DHW thermostat ¦ Limit thermostat HC ¦ Start prevention ¦ Boiler flow
switch ¦ Boiler pressure switch ¦ Consumer request VK1 10V ¦ Consumer request VK2 10V ¦ Pressure measurement 10V ¦ Output
request 10V
6055 Contact type H2 module 2
NC ¦ NO
6057 Voltage value 1 H2 module 2
6058 Funct value 1 H2 module 2
6059 Voltage value 2 H2 module 2
6060 Funct value 2 H2 module 2
6062 Function input H2 module 3
None ¦ Optg mode change HCs+DHW ¦ Optg mode changeover DHW ¦ Optg mode changeover HCs ¦ Optg mode changeover
HC1 ¦ Optg mode changeover HC2 ¦ Optg mode changeover HC3 ¦ Heat generation lock ¦ Error/alarm message ¦ Consumer
request VK1 ¦ Consumer request VK2 ¦ Release swi pool source heat ¦ Excess heat discharge ¦ Release swi pool solar ¦
Operating level DHW ¦ Operating level HC1 ¦ Operating level HC2 ¦ Operating level HC3 ¦ Room thermostat HC1 ¦ Room
thermostat HC2 ¦ Room thermostat HC3 ¦ DHW flow switch ¦ DHW thermostat ¦ Limit thermostat HC ¦ Start prevention ¦ Boiler flow
switch ¦ Boiler pressure switch ¦ Consumer request VK1 10V ¦ Consumer request VK2 10V ¦ Pressure measurement 10V ¦ Output
request 10V
6063 Contact type H2 module 3
NC ¦ NO
6065 Voltage value 1 H2 module 3
6066 Function value 1 H2 module 3
6067 Voltage value 2 H2 module 3
6068 Function value 2 H2 module 3
6072 Signal output UX
0..10V ¦ PWM
6078 Function output UX2
None ¦ Boiler pump Q1 ¦ DHW pump Q3 ¦ DHW interm circ pump Q33 ¦ Heat circuit pump HC1 Q2 ¦ Heat circuit pump HC2 Q6 ¦
Heat circuit pump HC3 Q20 ¦ Collector pump Q5 ¦ Solar pump ext exch K9 ¦ Solar pump buffer K8 ¦ Solar pump swi pool K18 ¦
Instant WH pump Q34
[6554.2] Calib output UX2 Hq
6085 Function output P1
None ¦ Boiler pump Q1 ¦ DHW pump Q3 ¦ DHW interm circ pump Q33 ¦ Heat circuit pump HC1 Q2 ¦ Heat circuit pump HC2 Q6 ¦
Heat circuit pump HC3 Q20 ¦ Collector pump Q5 ¦ Solar pump ext exch K9 ¦ Solar pump buffer K8 ¦ Solar pump swi pool K18 ¦
Instant WH pump Q34
6089 Function output UX3
None ¦ Boiler pump Q1 ¦ DHW pump Q3 ¦ DHW interm circ pump Q33 ¦ Heat circuit pump HC1 Q2 ¦ Heat circuit pump HC2 Q6 ¦
Heat circuit pump HC3 Q20 ¦ Collector pump Q5 ¦ Solar pump ext exch K9 ¦ Solar pump buffer K8 ¦ Solar pump swi pool K18 ¦
Instant WH pump Q34
[6554.3] Calib output UX3
6097 Sensor type collector
NTC ¦ Pt 1000
6098 Readjustm collector sensor
6100 Readjustm outside sensor
6101 Sensor type flue gas temp
NTC ¦ Pt 1000 ¦ NTC 20k
6102 Readjustm flue gas sensor
6110 Time constant building
6116 Time constant setp compens
6117 Central setp compensation
6118 Setpoint drop delay
6120 Frost protection plant
Off ¦ On
6127 Pump/valve kick duration
LPB
