Page #49 background image
49/617
Building Technologies Division User Manual LMS14... CC1U7471en
5 Handling 28.01.2015
Line no.
Operating line
Default value
Min
Max
Unit
Operator unit ACS420 ACS700/ACS790
1000
Operating mode HC2
Protection ¦ Automatic ¦ Reduced ¦ Comfort
Operating mode heat circuit 2
Protection ¦ Automatic ¦ Reduced ¦ Comfort
Automatic -
1010 Comfort setpoint RoomTemp ComfSetp HC2 Room temperature Comfort setpoint
HC2
20.0 BZ 1012 BZ 1016 °C
1012 Reduced setpoint RmTmp RedSetp HC2 Room temp reduced setpoint heat
circuit 2
16 BZ 1014 BZ 1010 °C
1014 Frost protection setpoint RmTmpFrostProtSetpHC2 Room temp frost protection setpoint
HC2
10.0 4 BZ 1012 °C
1016 Comfort setpoint max ComfortSetp max HC2 Comfort setpoint max HC2 35.0 BZ 1010 35 °C
1020 Heating curve slope Heating curve 2 slope Heating curve 2 slope 1.50 0.10 4.00 -
1021 Heating curve displacement HeatCurvParalDisplHC2 Heating curve parallel displacement
HC2
0.0 -4.5 4.5 °C
1026 Heating curve adaption
Off ¦ On
HeatCurve adapt HC2
Off ¦ On
Heating curve adaptation heat
circuit 2
Off ¦ On
Off -
1030 Summer/winter heating limit Su/WiChangeoverTmpHC2 Summer/winter changeover temp
heat circuit 2
18 /8 30 °C
1032 24-hour heating limit 24-HourHeatLimit HC2 24-hour heating limit HC2 -3 /-10 10 °C
1033 Ext’n 24-hour heating limit
No ¦ Yes
Ext 24hour heatLimHC2
No ¦ Yes
Ext’n 24-hour heating limit HC2
No ¦ Yes
Yes
1040 Flow temp setpoint min FlowTmp MinLimitn HC2 Flow temp min limitation heat circuit
2
8 8 BZ 1041 °C
1041 Flow temp setpoint max FlowTmp MaxLimitn HC2 Flow temp max limitation heat
circuit 2
80 BZ 1040 95 °C
1042 Flow temp setpoint room stat FlowSetpRoomthermoHC2 Flow temp setpoint room thermostat
HC2
65 /BZ
1040
BZ 1041 °C
1044 Swi-on ratio room stat SwiOn ratio rthstatHC2 Swi on ratio room thermosta HC2 /1 99 %
1046 Delay heat request Delay HeatRequest HC2 Delay heat request HC2 0 0 600 s
1050 Room influence RmTmp gain factor HC2 Room temp gain factor heat circuit
2
20 /1 100 %
1060 Room temp limitation RT limitation HC 2 Room temperature limitation
heating circuit 2
1 /0.5 4 °C
1061 Heating limit room controller Heating limit RC HC2 Heating limit room control HC2 /0 100 %
1070 Boost heating RmTmp SetpBoost HC2 Room temp setpoint boost HC2
(boost heating)
5 /0 20 °C
