Siemens LMS14

50/617
Building Technologies Division User Manual LMS14... CC1U7471en
5 Handling 28.01.2015
Line no.
Operating line
Default value Min Max Unit
Operator unit ACS420 ACS700/ACS790
1080 Quick setback
Off ¦ To Reduced setpoint ¦ To frost Prot setpoint
Quick setback HC2
Off ¦ Down to reduced setp ¦ Down to frost
prot setp
Quick setback heat circuit 2
Off ¦ Down to reduced setp ¦ Down to frost
prot setp
To Reduced setpoint -
1090 Optimum start control max OptStartCtrl MaxTime2 Optimum start control max forward
shift HC2
0 0 360 Min.
1091 Optimum stop control max OptStopCtrl MaxTime2 Optimum stop control max forward
shift HC2
0 0 360 Min.
1094 Heat up gradient Heat up gradient Heat up gradient 60 0 600 min/k
1100 Reduced setp increase start StartRedRTSetpIncrHC2 Start reduced room temp setpoint
increase HC2
     /BZ
1101
10 °C
1101 Reduced setp increase end EndRedRTSetpIncrHC2 End reduced room temp setpoint
increase HC2
-15 -30 BZ 1100 °C
1109 Continuous pump operation
No ¦ Yes
Continuous PumpOp HC2
No ¦ Yes
Continuous pump operation HC2
No ¦ Yes
No
1112 Frost protection flow temp
Off ¦ On
FrostProtFlowTemp HC2
Off ¦ On
Frost protection flow temp HC2
Off ¦ On
On
1120 Opertemp prot pump circuit
Off ¦ On
RoomTemp ComfSetp HC3
Off ¦ On
Pump heating circuit overtemp
protection HC2
Off ¦ On
On
-
1130 Mixing valve boost MixValveSetpBoost HC2 Mixing valve setpoint boost heating
circuit 2
5 0 50 °C
1132 Actuator type
2-position ¦ 3-position
Actuator CtrlMode HC2
Two-position ¦ Three-position
Actuator control mode heat circuit 2
Two-position ¦ Three-position
Three-position -
1133 Switching differential 2-pos Actuator SwiDiff HC2 Actuator switching differential heat
circuit 2
2 0 20 °C
1134 Actuator running time Actuator RunTime HC2 Actuator running time heat circuit 2 120 30 873 s
1135 Mixing valve Xp Xp heating circuit 2 P-band (Xp) heat circuit 2 32 1 100 °C
1136 Mixing valve Tn Tn heating circuit 2 Integral action time (Tn) heat circuit
2
120 10 873 s
1150 Floor curing function
Off ¦ Functional heating ¦ Curing heating ¦
Functional/curing heating ¦ Curing/functional
heating ¦ Manually
FloorPlastrDryUpFnct2
Off ¦ Functional heating ¦ Curing heating ¦
Functional and curing heating ¦ Curing and
functional heating ¦ Manually
Flooring plaster dry up function HC1
Off ¦ Functional heating ¦ 'Belegreif'
heating ¦ Functional + 'Belegreif' heating ¦
Belegreif' + functional heating ¦ Manuell
Off -
1151 Floor curing setp manually FloorSetp man HC2 Floor setpoint manually HC2 25 0 95 °C
1155 Floor curing setp current FlowTmpSetFloorPlast2 Flow temp setpoint flooring plaster 0 95 °C
