Building Technologies Division User Manual LMS14… CC1U7471en
6 The settings in detail 28.01.2015
Stick format error
Wrong customer number on the stick, or data format on the stick unknown and cannot
be evaluated by the LMS14…
Check data set
When reading a data set from the stick to the LMS14…, a problem occurred, causing
no abortion, however. For example, a data point in the LMS14… is write-protected or
not available, but shall be changed.
Data set disabled
Data set may not be transferred to the LMS14… (read protection). For example, data
set is the backup.
Reading disabled
Parameter setting state is in the ABORT state. To cancel the parameter setting state,
only limited actions are available.
Line no. Operating line
[4566.1] SerNumb para stick
This data point shows the series number of the parameter stick with which the LMS14...
was parameterized last.
If an error occurs while setting parameters with the stick, the LMS14... switches to the
parameter setting state.
To reset the parameter setting state with the stick, a stick with this series number is
required.
Line no. Operating line
[4693.1] Para stick stor pos
If the LMS14... is parameterized with the stick, the position of the data set is stored in
EEPROM here.
If an error occurs while setting parameters with the stick, the LMS14... switches to the
parameter setting state.
To reset the parameter setting state with the stick, the data set is exactly this location.
Line no. Operating line
[4733.1]
OEM PStick DataSetNum
When the OEM creates a data set, the ACS435 setup manager assigns automatically
an OEM data set number. During parameterization, the stick downloads this number to
the LMS14... where it is stored in this data point.
Line no. Operating line
[4734.1]
HQ PStick DataSetNum
When Siemens headquarters creates a data set, the ACS435 setup manager assigns
automatically a headquarters data set number. During parameterization, the stick
downloads this number to the LMS14... where it is stored in this data point.
SerNumb para stick
Para stick stor pos
OEM PStick
DataSetNum
HQ PStick DataSetNum
