Siemens LMS14

52/617
Building Technologies Division User Manual LMS14... CC1U7471en
5 Handling 28.01.2015
Line no.
Operating line
Default value Min Max Unit
Operator unit ACS420 ACS700/ACS790
1310 Comfort setpoint RoomTemp ComfSetp HC3/P Room temperature Comfort setpoint
HC3/P
20.0 BZ 1312 BZ 1316 °C
1312 Reduced setpoint RedRTSetp HC3/P Reduced room temperature setpoint
HCP
16 BZ 1314 BZ 1310 °C
1314 Frost protection setpoint RTFrostProtSetp HC3/P Room temperature frost protection
setpoint HC3/P
10.0 4 BZ 1312 °C
1316 Comfort setpoint max ComfSetp max HC3/P Comfort setpoint max HC3/P 35.0 BZ 1310 35 °C
1320 Heating curve slope HeatCurvSlope HC3/P Heating curve slope HC3/P 1.50 0.10 4.00 -
1321 Heating curve displacement HeatCurvParalDisplHCP Heating curve parallel displacement
HC3/P
0.0 -4.5 4.5 °C
1326 Heating curve adaption
Off ¦ On
HeatCurvAdaptHC3/P
Off ¦ On
Heating curve adaption HC3/P
Off ¦ On
Off
-
1330 Summer/winter heating limit Su/WiCh’overT HC3/P Summer/winter changeover
temperature HC3/P
18    / 8 30 °C
1332 24-hour heating limit 24-HourHeatLim HC3/P 24-hour heating limit HC3/P -3    / -10 10 °C
1333 Ext’n 24-hour heating limit
No ¦ Yes
Ext 24hour heatLimHC3
No ¦ Yes
Ext'n 24-hour heating limit HC3
No ¦ Yes
Yes
1340 Flow temp setpoint min FT min Limit HC3/P Flow temperature min limitation
HC3/P
8 8 BZ 1341 °C
1341 Flow temp setpoint max FT max Limit HC3/P Flow temperature max limitation
HC3/P
80 BZ 1340 95 °C
1342 Flow temp setpoint room stat FlowRoomthermoHC3/P Flow temp setpoint room thermostat
HC3/P
65    / BZ
1340
BZ 1341 °C
1344 Swi-on ratio room stat SwiOnRatioRthstaHC3/P Swi on ratio room thermosta HC3/P       / 1 99 %
1346 Delay heat request Delay HeatRequest HC3 Delay heat request HC3 0 0 600 s
1350 Room influence RT Authority HC3/P Room temperature authority HC3/P 20    / 1 100 %
1360 Room temp limitation RT Limitation HC3/P Room temperature limitation HC3/P 1    / 0,5 4 °C
1361 Heating limit room controller Heating lim RC HC3/P Heating limit room controller HC3/P       / 0 100 %
1370 Boost heating RoomSetpBoost HC3/P Room setpoint boost HC3/P (boost
heating)
5    / 0 20 °C
1380 Quick setback
Off ¦ To Reduced setpoint ¦ To frost Prot setpoint
QuickSetback HC3/P
Off ¦ Down to reduced setp ¦ Down to frost
prot setp
Quick setback HC3/P
Off ¦ Down to reduced setp ¦ Down to frost
prot setp
To Reduced setpoint -
1390 Optimum start control max OptStartMaxShift 3/P Optimum start control max forward
shift HC3/P
0 0 360 Min.
