Siemens LMS14

53/617
Building Technologies Division User Manual LMS14... CC1U7471en
5 Handling 28.01.2015
Line no.
Operating line
Default value Min Max Unit
Operator unit ACS420 ACS700/ACS790
1391 Optimum stop control max OptStopMaxShift 3/P Optimum stop control max forward
shift HC3/P
0 0 360 Min.
1394 Heat up gradient Heat up gradient Heat up gradient 60 0 600 min/K
1400 Reduced setp increase start StartRedRTIncrHC3/P Start reduced room temp setpoint
increase HC3/P
      / BZ
1401
10 °C
1401 Reduced setp increase end EndRedRTIncrHC3/P End reduced room temp setpoint
increase HC3/P
-15 -30 BZ 1400 °C
1409 Continuous pump operation
No ¦ Yes
Continuous PumpOp HC3
No ¦ Yes
Continuous pump operation HC3
No ¦ Yes
No
1412 Frost protection flow temp
Off ¦ On
FrostProtFlowTemp HC3
Off ¦ On
Frost protection flow temp HC3
Off ¦ On
On
1420 Overtemp prot pump circuit
Off ¦ On
DHW NomSetp
Off ¦ On
Pump heating circuit overtemp
protection HC3/P
Off ¦ On
On
-
1430 Mixing valve boost MixValveBoost HC3/P Mixing valve setpoint boost heating
circuit 3/P
5 0 50 °C
1432 Actuator type
2-position ¦ 3-position
ActuatorCtrlMod HC3/P
Two-position ¦ Three-position
Actuator control mode heat circuit
3/P
Two-position ¦ Three-position
Three-position -
1433 Switching differential 2-pos ActuatorSwiDiff HC3/P Actuator switching differential heat
circuit 3/P
2 0 20 °C
1434 Actuator running time ActuatorRunTime HC3/P Actuator running time heat circuit
3/P
120 30 873 s
1435 Mixing valve Xp Xp heating circuit 3/P P-band (Xp) heat circuit 3/P 32 1 100 °C
1436 Mixing valve Tn Tn heating circuit 3/P Integral action time (Tn) heat circuit
3/P
120 10 873 s
1450 Floor curing function
Off ¦ Functional heating ¦ Curing heating ¦
Functional/curing heating ¦ Curing/functional
heating ¦ Manually
FloorCurFunct HC3/P
Off ¦ Functional heating ¦ Curing heating ¦
Functional and curing heating ¦ Curing and
functional heating ¦ Manually
Floor curing function HC3/P
Off ¦ Functional heating ¦ 'Belegreif'
heating ¦ Functional + 'Belegreif' heating ¦
Belegreif' + functional heating ¦ Manuell
Off -
1451 Floor curing setp manually FloorSetp man HC3/P Floor setpoint manually HC3/P 25 0 95 °C
1455 Floor curing setp current FTSetpFloorCur HC3/P Flow temperature setpoint floor
curing HC3/P
0 95 °C
1456 Floor curing day current DHW TempActTop B3/BMU Floor curing day HC3/P 0 32
1461 Excess heat draw Overtemp drop HC3/P Overtemperature drop heating Always
