Siemens LMS14

55/617
Building Technologies Division User Manual LMS14... CC1U7471en
5 Handling 28.01.2015
Line no.
Operating line
Default value Min Max Unit
Operator unit ACS420 ACS700/ACS790
1620 Release
24h/day ¦ Time programs HCs ¦ Time program
4/DHW
DHW Release
24h/day ¦ Heating programs with forward
shift ¦ Time switch program 4
DHW release
24h/day ¦ Heating programs with forward
shift ¦ Time switch program 4
Heating programs
with forward shift
-
1630 Charging priority
Absolute ¦ Shifting ¦ None ¦ MC shifting, PC
absolute
DHW Charging Priority
Absolute ¦ Shifting ¦ None (parallel) ¦
Shifting, absolute
DHW charging priority
Absolute ¦ Shifting ¦ None (parallel) ¦
Shifting, absolute
Shifting, absolute -
1640 Legionella function
Off ¦ Periodically ¦ Fixed weekday
Legionella function
Off ¦ Periodically ¦ Fixed Weekday
Legionella function
Off ¦ Periodically ¦ Fixed weekday
Fixed weekday -
1641 Legionella funct periodically LegioFunctPeriodicity Legionella function periodicity 3 1 7 Days
1642 Legionella funct weekday
Monday ¦ Tuesday ¦ Wednesday ¦ Thursday ¦
Friday ¦ Saturday ¦ Sunday
LegioFunction Day
Monday ¦ Tuesday ¦ Wednesday ¦
Thursday ¦ Friday ¦ Saturday ¦ Sunday
Legionella function day
Monday ¦ Tuesday ¦ Wednesday ¦
Thursday ¦ Friday ¦ Saturday ¦ Sunday
Monday
1644 Legionella funct time Time LegioFunkt Time for legionella function       / 00:00 23:50 hh:mm
1645 Legionella funct setpoint LegionellaFunctSetp Legionella function setpoint 65 55 95 °C
1646 Legionella funct duration DwellTimeLegFunctSetp Dwelling time at legionella function
setpoint
30    / 10 360 Min.
1647 Legionella funct circ pump
Off ¦ On
CirculPumpOpLegioFunct
Off ¦ On
Circul. pump operation during
legionella func
Off ¦ On
On -
1660 Circulating pump release
Time program 3/HC3 ¦ DHW release ¦ Time
program 4/DHW ¦ Time program 5
DHW CircPump Release
Time switch program 3 ¦ DHW release ¦
Time switch program 4 ¦ Time switch
program 5
DHW circulating pump release
Time switch program 3 ¦ DHW release ¦
Time switch program 4 ¦ Time switch
program 5
DHW release -
1661 Circulating pump cycling
Off ¦ On
DHW CircPump cycling
Off ¦ On
DHW circulating pump cycling
Off ¦ On
On -
1663 Circulation setpoint DHW Circ Setpoint DHW circulation setpoint 45 8 80 °C
1680 Optg mode changeover
None ¦ Off ¦ On
OptgModeCh’over DHW
None ¦ Off ¦ On
Operating mode changeover DHW
None ¦ Off ¦ On
Off
Consumer circuit 1
1859 Flow temp setp cons request FlowTSetpConsReq 1 Flow temp setp cons request 1 70 8 120 °C
1874 DHW charging priority
No ¦ Yes
DHWChargPrioCC1
No ¦ Yes
DHW charging priority consumer
circuit 1
No ¦ Yes
Yes
1875 Excess heat draw
Off ¦ On
Overtemp drop CC1
Off ¦ On
Overtemperature drop consumer
circuit 1
On
