Siemens LMS14

56/617
Building Technologies Division User Manual LMS14... CC1U7471en
5 Handling 28.01.2015
Line no.
Operating line
Default value Min Max Unit
Operator unit ACS420 ACS700/ACS790
Off ¦ On
1878 With buffer
No ¦ Yes
CC1 With buffer
No ¦ Yes
Consumer circuit 1 with buffer
No ¦ Yes
Yes
1880 With prim contr/system pump
No ¦ Yes
CC1 prectrl/PrimPump
No ¦ Yes
Consumer circuit 1 with
precontr/primary pump
No ¦ Yes
Yes
Consumer circuit 2
1909 Flow temp setp cons request FlowTSetpConsReq 2 Flow temp setp cons request 2 70 8 120 °C
1924 DHW charging priority
No ¦ Yes
DHWChargPrioCC2
No ¦ Yes
DHW charging priority consumer
circuit 2
No ¦ Yes
Yes
1925 Excess heat draw
Off ¦ On
Overtemp drop CC2
Off ¦ On
Overtemperature drop consumer
circuit 2
Off ¦ On
On
1928 With buffer
No ¦ Yes
CC2 With buffer
No ¦ Yes
Consumer circuit 2 with buffer
No ¦ Yes
Yes
1930 With prim contr/system pump
No ¦ Yes
CC2 precontr/PrimPump
No ¦ Yes
Consumer circuit 2 with
precontr/primary pump
No ¦ Yes
Yes
Swimming pool circuit
1959 Flow temp setpoint FlowTSetp pool Flow temp setp pool 70 8 120 °C
1974 DHW charging priority
No ¦ Yes
DHWChargPrioPool
No ¦ Yes
DHW charging priority swimming
pool circuit
No ¦ Yes
Yes
1975 Excess heat draw
Off ¦ On
Overtemp drop Pool
Off ¦ On
Overtemperature drop swimming
pool circuit
Off ¦ On
On
1978 With buffer
No ¦ Yes
Pool With buffer
No ¦ Yes
Swimming pool circuit with buffer
No ¦ Yes
Yes
1980 With prim contr/system pump
No ¦ Yes
PoolPrecotr/PrimPump
No ¦ Yes
Swimming pool circuit with
precontr/primary pump
No ¦ Yes
Yes
Swimming pool
2055 Setpoint solar heating Pool setpoint solar Pool setpoint solar heating 26 8 80 °C
2056 Setpoint source heating Pool setp producer Pool setpoint producer heating 22 8 80 °C
