Siemens LMS14

57/617
Building Technologies Division User Manual LMS14... CC1U7471en
5 Handling 28.01.2015
Line no.
Operating line
Default value Min Max Unit
Operator unit ACS420 ACS700/ACS790
2065 Charging priority solar
Priority 1 ¦ Priority 2 ¦ Priority 3
PoolChargPrioritySol
Priority 1 ¦ Priority 2 ¦ Priority 3
Pool charging priority solar
Priority 1 ¦ Priority 2 ¦ Priority 3
Priority 3
2070 Swimming pool temp max Pool temp max Pool temperature maximum 32 BZ 2055 95 °C
2080 With solar integration
No ¦ Yes
Pool with solar
No ¦ Yes
Pool with solar
No ¦ Yes
Yes
Primary contr/system pump
2110 Flow temp setpoint min FT MinLimitn Precontr Flow temp min limitation
precontroller
8 8 BZ 2111 °C
2111 Flow temp setpoint max FT MaxLimitn Precontr Flow temp max limitation
precontroller
80 BZ 2110 95 °C
2121 Syst pump on heat gen lock
Off ¦ On
SystPump HeatGenLock
Off ¦ On
System pump on heat gen lock
Off ¦ On
Off
2130 Mixing valve boost MixVaSetpBoostPreC Mixing valve setpoint boost
precontroller
10 0 50 °C
2132 Actuator type
2-position ¦ 3-position
Actuator CtrlMod PreC
Two-position ¦ Three-position
Actuator control mode precontroller
Two-position ¦ Three-position
Three-position
2133 Switching differential 2-pos Actuator SwiDiff PreC Actuator switching differential
precontroller
2 0 20 °C
2134 Actuator running time Actuator RunTime PreC Actuator running time precontroller 120 30 873 s
2135 Mixing valve Xp Xp precontroller P-band (Xp)precontroller 32 1 100 °C
2136 Mixing valve Tn Tn precontroller Integral action time (Tn)
precontroller
120 10 873 s
2150 Primary contr/system pump
Before buffer ¦ After buffer
Precontr/PrimPump
Upstream of buffer ¦ Downstream from
buffer
Precontroller/primary pump
Upsstream of buffer ¦ Downstream from
buffer
Downstream from
buffer
-
Boiler
2203 Release below outside temp ReleaseOil/GasBelowTh Release oil-/gas boil below outside
temp thresh
0 - - - / -50 50 °C
2208 Full charging buffer
Off ¦ On
Full charging buffer
Off ¦ On
Full charging buffer
Off ¦ On
Off
2210 Setpoint min BoilTmp MinLimitn Boiler temp min limitation 40 BZ 2211 BZ2214 °C
2211 Setpoint min OEM BoilTmp MinLimitn OEM Boiler temp min limitation OEM 40 8 BZ 2210 °C
2212 Setpoint max BoilTmp MaxLimitn Boiler temp max limitation 80 BZ 2214 BZ 2213 °C
2213 Setpoint max OEM BoilTmp MaxLimitn OEM Boiler temp max limitation OEM 85 BZ 2212 120 °C
2214 Setpoint manual control BoilerSetp man Boiler temperature setpoint in 60 BZ 2210 BZ 2212 °C
