Building Technologies Division User Manual LMS14… CC1U7471en
6 The settings in detail 28.01.2015
Error
code
LPB
code
Description of error Priority
209 Fault heating circuit 3
209 Fault heating circuit 6
214 Monitoring of motor 6
215 Fault fan air diverting valve 9
216 Fault boiler 6
216 Fault boiler 9
217 Sensor error 3
217 Sensor error 6
217 Sensor error 9
218 Pressure supervision 6
218 Pressure supervision 9
241 Flow sensor for yield measurement, error 6
242 Return sensor for yield measurement, error 6
243 Swimming pool sensor, error 6
260 217 Flow temperature 3, sensor error 3
270 215 Temperature difference, heat exchanger too large 9
317 214 Mains frequency outside permissible range 6
320 217 DHW charging temperature, sensor error 6
321 217 DHW outlet temperature, sensor error 6
322 218 Water pressure 3 too high 6
322 218 Water pressure 3 too high 9
323 218 Water pressure 3 too low 6
323 218 Water pressure 3 too low 9
324 146 Input BX, same sensors 3
325 146 Input BX/extension module, same sensors 3
326 146 Input BX/mixing group, same sensors 3
327 146 Extension module, same function 3
328 146 Mixing group, same function 3
329 146 Extension module/mixing group, same function 3
330 146 Sensor input BX1 without function 3
331 146 Sensor input BX2 without function 3
332 146 Sensor input BX3 without function 3
333 146 Sensor input BX4 without function 3
335 146 Sensor input BX21 without function 3
336 146 Sensor input BX22 without function 3
339 146 Collector pump Q5 missing 3
340 146 Collector pump Q16 missing 3
341 146 Sensor B6 missing 3
342 146 Solar charging sensor B31 missing 3
343 146 Solar integration missing 3
344 146 Solar controlling element buffer K8 missing 3
345 146 Solar controlling element swimming pool K18 missing 3
346 146 Solid fuel boiler pump Q10 missing 3
347 146 Solid fuel boiler comparative sensor missing 3
348 146 Solid fuel boiler address error 3
349 146 Buffer storage tank return valve Y15 missing 3
350 146 Buffer storage tank address error 3
351 146 Primary controller/system pump, address error 3
352 146 Pressureless header, address error 3
353 146 Sensor B10 missing 3
371 209 Flow temperature heating circuit 3 6
372 209 Temperature limiter heating circuit 3 3
373 103 Extension module 3 8
374 169 Sitherm Pro calculation 6
374 169 Sitherm Pro calculation 9
375 169 BV stepper motor 9
