64/617
Building Technologies Division User Manual LMS14... CC1U7471en
5 Handling 28.01.2015
Line no.
Operating line
Default value Min Max Unit
Operator unit ACS420 ACS700/ACS790
3816 Temp diff on swi pool TempDiffSwimmPoolON Temperature differential swimming
pool ON
      /
BZ 3817
40 °C
3817 Temp diff off swi pool TempDiffSwimmPoolOFF Temperature differential swimming
pool OFF
      / 0 BZ 3816 °C
3818 Charging temp min swi pool MinChargTemp Pool Min charging temperature
swimming pool
      / 8 95 °C
3822 Charging prio storage tank
None ¦ DHW storage tank ¦ Buffer storage tank
ChargingPriority stor
None ¦ DHW storage tank ¦ Buffer
Charging priority storage
None ¦ DHW storage tank ¦ Buffer
DHW storage tank
3825 Charging time relative prio Charg time rel prio Charging time relative priority       / 2 60 Min.
3826 Waiting time relative prio Wait time rel prio Wait time relative priority 5 1 40 Min.
3827 Waiting time parallel op Wait time parallel Wait time parallel operation       / 0 40 Min.
3828 Delay secondary pump Start delay sec pump Start delay secondary pump 60 0 600 s
3830 Collector start function Coll Start function Collector Start function       / 5 60 Min.
3831 Min run time collector pump Min Coll Pump RunTime Min collector pump running time 20 5 120 s
3832 CollStart function on Collector Start function on 07:00 00:00 23:50 hh:mm
3833 CollStartFunction off Collector Start function off 19:00 00:00 23:50 hh:mm
3834 CollStartFunction Gra Collector Start function gradient       / 1 20 Min./°C
3840 Collector frost protection CollectorFrostProtTmp Collector frost protection temp       / -20 5 °C
3850 Collector overtemp prot CollOvertempProt Collector overtemperature
protection
      / 30 350 °C
3860 Evaporation heat carrier EvaporationTemp Evaporation temperature of heat
carrier
      / 60 350 °C
3865 Starting speed coll pump 1 StartSpeedColl pump 1 Starting speed coll pump 1 100    / 0 100 %
3867 Starting speed exch pump StartSpeed exch pump Starting speed exch pump 100    / 0 100 %
3868 Starting speed buffer pump StartSpeed buf pump Starting speed buffer pump 100    / 0 100 %
3869 Starting speed swi pool pump StartSpeed SwiPool pu Starting speed swi pool pump 100    / 0 100 %
3870 Pump speed min Pump speed min solar Pump speed min solar 40 BZ 3875 BZ 3871 %
3871 Pump speed max Pump speed max solar Pump speed max solar 100 BZ 3870 BZ 3876 %
3872 Speed Xp Pump speed XP sol Pump speed P-band XP solar 32 1 100 °C
3873 Speed Tn Pump speed Tn solar Pump speed Integral action time Tn
solar
120 10 873 s
3875 Pump speed min OEM Pump speed minOEM sol Pump speed min OEM solar 40 0 BZ 3870 %
3876 Pump speed max OEM Pump speed max OEM Pump speed max OEM 100 BZ 3871 100 %
