Siemens LMS14 - Page 65

65/617
Building Technologies Division User Manual LMS14... CC1U7471en
5 Handling 28.01.2015
Line no.
Operating line
Default value Min Max Unit
Operator unit ACS420 ACS700/ACS790
3880 Antifreeze
None ¦ Ethylene glycol ¦ Propylene glycol ¦ Etyl and
propyl glycol
TypeAntifreezeAdded
None (water) ¦ Ethylenglycol ¦
Propylenglycol ¦ Mixture Ethylen- and
Propylenglycol
Type of antifreeze added
None (water) ¦ Ethylenglycol ¦
Propylenglycol ¦ Mixture Ethylen- and
Propylenglycol
None
3881 Antifreeze concentration AntifreezeConcentrat Antifreeze concentration 30 1 100 %
3884 Pump capacity VolumetricFlowSolPump Volumetric flow solar pump 200 10 1500 l/h
3887 Pulse unit yield Pulse unit yield Pulse unit yield 10 0 100 l
Solid fuel boiler
4102 Locks other heat sources
Off ¦ On
SolidFuel LocksProduc
Off ¦ On
Solid fuel boiler locks other
producers
Off ¦ On
On
4110 Setpoint min SetpMin solid fuel Min solid fuel boiler setpoint 40 8 120 °C
4130 Temp diff on TmpDiff on solid fuel Temp differential on solid fuel boiler 8 BZ 4131 but
min. 1
40 °C
4131 Temp diff off TmpDiffOff solid fuel Temp differential off solid fuel boiler 4 0 BZ 4130 °C
4133 Comparative temp
DHW sensor B3 ¦ DHW sensor B31 ¦ Buffer sensor
B4 ¦ Buffer sensor B41 ¦ Flow temp setpoint ¦
Setpoint min
ComparTemp SolidFuel
DHW sensor B3 ¦ DHW sensor B31 ¦
Buffer sensor B4 ¦ Buffer sensor B41 ¦
Flow temp setpoint ¦ Setpoint min
Comparative temperature solid fuel
boiler
DHW sensor B3 ¦ DHW sensor B31 ¦
Buffer sensor B4 ¦ Buffer sensor B41 ¦
Flow temp setpoint ¦ Setpoint min
Setpoint min
4140 Pump overrun time PumpOverrun SolidFuel Pump overrun time solid fuel boiler 20 0 120 Min.
4141 Excess heat discharge OverTmpDrop SolidFuel Overtemperature drop solid fuel
boiler
90 60 140 °C
4170 Frost prot plant boiler pump
Off ¦ On
FrostPlntSolidFuelPmp
Off ¦ On
Frost protection for plant solid fuel
boiler
Off ¦ On
Off
Buffer storage tank
4720 Auto generation lock
None ¦ With B4 ¦ With B4 and B42/B41
Auto producer lock
None ¦ With B4 ¦ With B4 and B42/B41
Automatic producer lock
None ¦ With B4 ¦ With B4 and B42/B41
With B4 -
4721 Auto heat gen lock SD Auto producer lock SD Automatic generation lock switching
differential
8 0 20 °C
4722 Temp diff buffer/HC Diff. Buffer/HC Diff. Buffer/HC temp to producer
release
-5 -20 20 °C
4724 Min st tank temp heat mode MinBufferTempHeatMode Min buffer temp while heating mode       / 8 95 °C
4750 Charging temp max Buffer Charg temp max Buffer charging temp max 80 8 BZ 4751 °C
