Building Technologies Division User Manual LMS14... CC1U7471en
5 Handling 28.01.2015
Line no.
Operating line
Default value Min Max Unit
Operator unit ACS420 ACS700/ACS790
5022 Type of charging
Recharging ¦ Full charging ¦ Full charging legio ¦
Full charg 1st time day ¦ Full charg 1st time legio
DHW RechargingControl
Recharging ¦ Full charging ¦ Full charging
legio ¦ Full charg. first time of day ¦ Full
charg. first time, Legio
DHW recharging control
Recharging ¦ Full charging ¦ Full charging
legio ¦ Full charg. first time of day ¦ Full
charg. first time, Legio
Full charging
5024 Switching diff DHW SwitchingDiff DHW switching differential 5 0 20 °C
5030 Charging time limitation DHW ChargTimeLimit DHW charging time limitation 150    / 10 600 Min.
5040 Discharging protection
Off ¦ Always ¦ Automatically
DHW DischargingProt
Off ¦ Always ¦ Automatically
DHW discharging protection
Off ¦ Always ¦ Automatically
Automatically
5050 Charging temp max DHW ChargTemp max DHW charging temperature max 80 8 BZ 5051 °C
5051 Storage tank temp max DHW StorTankTemp max DHW storage tank temperature max 90 BZ 5050 95 °C
5055 Recooling temp DHW ReturnCool Temp DHW storage tank return cooling
temperature
80 8 95 °C
5056 Recooling heat gen/HCs
Off ¦ On
DHWReturnCool Prod/HC
Off ¦ On
DHW storage tank return cooling
Producer/HC
Off ¦ On
Off -
5057 Recooling collector
Off ¦ Summer ¦ Always
DHWReturnCool Coll
Off ¦ Summer ¦ Always
DHW storage tank return cooling
Collector
Off ¦ Summer ¦ Always
Off -
5060 El imm heater optg mode
Substitute ¦ Summer ¦ Always
DHW el OptgMode
Backup Mode ¦ Summer only ¦ Always
DHW electric immersion heater
operating mode
Backup mode ¦ Summer only ¦ Always
Backup mode -
5061 El immersion heater release
24h/day ¦ DHW release ¦ Time program4/ DHW
DHW el Release
24h/day ¦ DHW release ¦ Time switch
program 4
DHW electric immersion heater
release
24h/day ¦ DHW release ¦ Time switch
program 4
DHW release -
5062 El immersion heater control
External thermostat ¦ DHW sensor
DHW el Control
External thermostat ¦ DHW sensor
DHW electric immersion heater
control
External thermostat ¦ DHW sensor
DHW sensor -
5070 Automatic push
Off ¦ On
DHW automatic Push
Off ¦ On
DHW automatic push
Off ¦ On
On
5071 Charging prio time push ChargPrioTimePush charging priority time push 0 0 120 Min.
5085 Excess heat draw
Off ¦ On
DHW overtemp drop
Off ¦ On
DHW storage tank overtemperature
drop
Off ¦ On
On -
5090 With buffer DHW buffer DHW storage tank with buffer No
