Siemens LMS14 - Page 68

68/617
Building Technologies Division User Manual LMS14... CC1U7471en
5 Handling 28.01.2015
Line no.
Operating line
Default value Min Max Unit
Operator unit ACS420 ACS700/ACS790
No ¦ Yes No ¦ Yes No ¦ Yes
5092 With prim contr/system pump
No ¦ Yes
DHW precontr/PrimPump
No ¦ Yes
DHW storage tank with
precontr/primary pump
No ¦ Yes
No
5093 With solar integration
No ¦ Yes
DHW with solar
No ¦ Yes
DHW storage tank with solar
No ¦ Yes
Yes
5101 Pump speed min Pump speed min DHW Pump speed min DHW 40 BZ 5106 BZ 5102 %
5102 Pump speed max Pump speed max DHW Pump speed max DHW 100 BZ 5101 BZ 5107 %
5103 Speed Xp Pump speed XP DHW Pump speed P-band XP DHW 32 1 100 °C
5104 Speed Tn Pump speed Tn DHW Pump speed Integral action time Tn
DHW
120 10 873 s
5105 Speed Tv Speed Tv Speed Tv 0 0 60 s
5106 Pump speed min OEM Pump speed minOEM DHW Pump speed min OEM DHW 40 0 BZ 5101 %
5107 Pump speed max OEM Pump speed max OEM Pump speed max OEM 100 BZ 5102 100 %
5108 Starting speed charg pump Start SpeedCharg pump Starting speed charg pump 100 --- / 0 100 %
5109 St speed interm circ pump St speed IntermCircPu St speed interm circ pump 100 --- / 0 100 %
5130 Transfer strategy
Off ¦ Always ¦ DHW release
Transfer strategy
Off ¦ Always ¦ DHW release
Transfer strategy
Off ¦ Always ¦ DHW release
Always
5131 Comparison temp transfer
DHW sensor B3 ¦ DHW sensor B31
ComparTemp transfer
DHW sensor B3 ¦ DHW sensor B31
Comparative temperature transfer
DHW sensor B3 ¦ DHW sensor B31
DHW sensor B3
5139 Interm circ boost recharging IntermCircBoostRechar Interm circ boost recharging 2 0 10 °C
5140 Intermediate circuit boost DHW char’circ. boost DHW charging circuit boost 2 0 10 °C
5141 Excess interm circ temp max DHW charg cir.bo max DHW charging circuit boost max 2 2 20 °C
5142 Flow setp compensation delay Delay flowsetp. contr Delay flow set point contr 30 - - - / 0 60 s
5143 Flow setp compensation Xp Xp flow setp. contr Prop band flow setp. contr 24 1 100 °C
5144 Flow setp compensation Tn Tn flow setp. contr Int act time flow setp. contr 120 10 873 s
5145 Flow setp compensation Tv Tv flow setp. contr Der act time flow setp. contr 0 0 60 s
5146 Full charging with B36
No ¦ Yes
Full charge with B36
No ¦ Yes
Full charge with B36
No ¦ Yes
Yes
[2385.1]
ForeseeTmeDHWPriority Foreseeable time during dhw-
priority
240 0 240 s
[3196.1]
Tn BoilerTemp DHWPrio Tn boiler temp DHW priority 10 0 255 min
5148 Min start temp diff Q33 MinStartTDiffQ33 Min start temp diff Q33 0 - - - / -20 20 °C
5151 Excess interm circ temp del T Char’cir’exc’supv Charg’ cir excess superv delay 30 0 255 s
Instantaneous water heater
