Siemens LMS14 - Page 73

73/617
Building Technologies Division User Manual LMS14... CC1U7471en
5 Handling 28.01.2015
Line no.
Operating line
Default value Min Max Unit
Operator unit ACS420 ACS700/ACS790
5585 On time min dT contr 2 OnTimeMin dT contr2 On time min dT contr 2 0 0 250 S
5587
Pump/valve kick K22
Off | On
Pump/valve kick K22
Off | On
Pump/valve kick K22
Off | On
On -
Configuration
5700
Presetting
Changed ¦ Unchanged
PlantDiagram Sel
Changed ¦ Unchanged
Changed 1...4 -
Plant diagram selection - - - - - - / 1 4 -
Plant diagram selection validity
Changed ¦ Unchanged
Changed
5710 Heating circuit 1
Off ¦ On
HC 1
Off | On
Heating circuit 1
Off ¦ On
On -
5711 Cooling circuit 1
Off ¦ 4-pipe system cooling
Cooling circuit 1
Off ¦ 4-pipe system cooling
Cooling circuit 1
Off ¦ 4-pipe system cooling
Off -
5715 Heating circuit 2
Off ¦ On
HC 2
Off | On
Heating circuit 2
Off ¦ On
Off -
5721 Heating circuit 3
Off ¦ On
HC 3
Off | On
Heating circuit 3
Off ¦ On
Off -
5730 DHW sensor
DHW sensor B3 ¦ Thermostat | DHW outlet sensor
B38
DHW sensor
DHW sensor B3 ¦ Thermostat | DHW outlet
sensor B38
DHW sensor
DHW sensor B3 ¦ Thermostat | DHW outlet
sensor B38
DHW sensor B3 -
5731 DHW controlling element
No charging request ¦ Charging pump ¦ Diverting
valve
DHW Actuating Dev
No charging request ¦ Charging pump ¦
Diverting valve
DHW actuating device
No charging request ¦ Charging pump ¦
Diverting valve
Charging pump -
5732 Pump off change div valve Pump off change DV Pump-off time at change from
heating to DHW
0 0 10 s
5733 Delay pump off Delay pump off Pump-off delay at change from
heating to DHW
0 0 10 s
5734 Basic position DHW div valve
Last request ¦ Heating circuit ¦ DHW
BasicPos DHW div valv
Last request ¦ Heating circuit ¦ DHW
Basic pos DHW div valve
Last request ¦ Heating circuit ¦ DHW
Last request -
5736 DHW separate circuit
Off ¦ On
Dhw dedicated
Off ¦ On
Dhw dedicated
Off ¦ On
Off -
5737 Optg action DHW div valve
Position on DHW ¦ Position on heating circuit
Type DHW div valve
Position on DHW ¦ Position on heating
circuit
Contact type DHW div valve
Position on DHW ¦ Position on heating
circuit
Position on DHW -
