74/617
Building Technologies Division User Manual LMS14... CC1U7471en
5 Handling 28.01.2015
Line no.
Operating line
Default value
Min
Max
Unit
Operator unit ACS420 ACS700/ACS790
5738 Midposition DHW div valve
Off ¦ On
MidPos DHW div valve
Off | On
Midposition DHW div valve
Off ¦ On
Off -
[4486.1]
DV-DHW steps Ph1 Numb steps, div valve DHW step
motor startup ph
20 0 600
[4489.1]
DV-DHW step dur Ph1 Dur (sub) step, div valve DHW in
startup ph
Eight-step 120
[4483.1]
DV-DHW step size Ph1
Full step ¦ Half-step ¦ Quarter-step ¦ Eight
step
Step size, div valve DHW step mot
in startup ph
Full step ¦ Half-step ¦ Quarter-step ¦ Eight
step
Eight-step
[4487.1]
DV-DHW steps Ph2 Numb steps, div valve DHW step
mot in adjust ph
385 0 600
[4490.1]
DV-DHW step due Ph2
Full step ¦ Half-step ¦ Quarter-step ¦ Eight
step
Dur (part) step, div valve DHW in
adjust ph
Full step ¦ Half-step ¦ Quarter-step ¦ Eight
step
Eight-step 120
[4484.1]
DV-DHW step size Ph2
Full step ¦ Half-step ¦ Quarter-step ¦ Eight
step
Step size, div valve DHW step mot
in adjust ph
Full step ¦ Half-step ¦ Quarter-step ¦ Eight
step
[4488.1]
DV-DHW steps Ph3 Numb steps, div valve DHW step
motor in end ph
75 0 600
[4491.1]
DV-DHW step dur Ph3 Dur (part) step, div valve DHW in
end ph
5 3 120
[4485.1]
DV-DHW step size Ph3
Full step ¦ Half-step ¦ Quarter-step ¦ Eight
step
Step size, div valve DHW step
motor in end ph
Full step ¦ Half-step ¦ Quarter-step ¦ Eight
step
Eight-step
5774 Ctrl boiler pump/DHW valve
All requests ¦ Request HC1/DHW only
ContrBoilPump/DHW val
All requests ¦ Request HC1/DHW only
Ctrl boiler pump/DHW valve
All requests ¦ Request HC1/DHW only
All requests -
5775 Boiler pump with DHW
On ¦ Off
Boiler pump with DHW
On ¦ Off
Boiler pump with DHW
On ¦ Off
On
5840 Solar controlling element
Charging pump ¦ Diverting valve
Solar Actuating Dev
Charging pump ¦ Diverting valve
Solar actuating device
Charging pump ¦ Diverting valve
Charging pump
5841 External solar exchanger Ext solar exchanger External solar exchanger Commonly
