Siemens LMS14 - Page 75

75/617
Building Technologies Division User Manual LMS14... CC1U7471en
5 Handling 28.01.2015
Line no.
Operating line
Default value Min Max Unit
Operator unit ACS420 ACS700/ACS790
Jointly ¦ DHW storage tank ¦ Buffer storage tank Commonly ¦ DHW storage tank ¦ Buffer
storage tank
Commonly ¦ DHW storage tank ¦ Buffer
storage tank
5870 Combi storage tank
Yes ¦ No
Combi Storage Tank
No ¦ Yes
Combi storage tank
No ¦ Yes
No -
5890 Relay output QX1
None ¦ Circulating pump Q4 ¦ El imm heater DHW
K6 ¦ Collector pump Q5 ¦ Cons circuit pump VK1
Q15 ¦ Boiler pump Q1 ¦ Bypass pump Q12 ¦ Alarm
output K10 ¦ 2nd pump speed HC1 Q21 ¦ 2nd
pump speed HC2 Q22 ¦ 2nd pump speed HC3 Q23
¦ Heat circuit pump HC3 Q20 ¦ Cons circuit pump
VK2 Q18 ¦ System pump Q14 ¦ Heat gen shutoff
valve Y4 ¦ Solid fuel boiler pump Q10 ¦ Time
program 5 K13 ¦ Buffer return valve Y15 ¦ Solar
pump ext exch K9 ¦ Solar ctrl elem buffer K8 ¦ Solar
ctrl elem swi pool K18 ¦ Swimming pool pump Q19
¦ Cascade pump Q25 ¦ St tank transfer pump Q11 ¦
DHW mixing pump Q35 ¦ DHW interm circ pump
Q33 ¦ Heat request K27 ¦ Refrigeration request K28
¦ Heat circuit pump HC1 Q2 ¦ Heat circuit pump
HC2 Q6 ¦ DHW ctrl elem Q3 ¦ Instant WH ctrl elem
Q34 ¦ Water refill K34 ¦ 2nd boiler pump speed Q27
¦ Status output K35 ¦ Status information K36 ¦ Flue
gas damper K37 ¦ Fan shutdown K38
¦ dT controller
1 K21 ¦ dT controller 2 K22
Relay Output QX1
None ¦ Circulating pump Q4 ¦ El imm
heater DHW K6 ¦ Collector pump Q5 ¦
Cons circuit pump VK1 Q15 ¦ Boiler pump
Q1 ¦ Bypass pump Q12 ¦ Alarm output K10
¦ 2nd pump speed HC1 Q21 ¦ 2nd pump
speed HC2 Q22 ¦ 2nd pump speed HC3
Q23 ¦ Heat circuit pump HC3 Q20 ¦ Cons
circuit pump VK2 Q18 ¦ System pump Q14
¦ Heat gen shutoff valve Y4 ¦ Solid fuel
boiler pump Q10 ¦ Time program 5 K13 ¦
Buffer return valve Y15 ¦ Solar pump ext
exch K9 ¦ Solar ctrl elem buffer K8 ¦ Solar
ctrl elem swi pool K18 ¦ Swimming pool
pump Q19 ¦ Cascade pump Q25 ¦ St tank
transfer pump Q11 ¦ DHW mixing pump
Q35 ¦ DHW interm circ pump Q33 ¦ Heat
request K27 ¦ Refrigeration request K28 ¦
Heat circuit pump HC1 Q2 ¦ Heat circuit
pump HC2 Q6 ¦ DHW ctrl elem Q3 ¦
Instant heater ctrl elem Q34 ¦ Water filling
K34 ¦ 2nd boiler pump speed Q27 ¦ Status
output K35 ¦ Status information K36 ¦ Flue
gas damper K37 ¦ Fan shutdown K38 ¦ dT
controller 1 K21 ¦ dT controller 2 K22
Relay output QX1
None ¦ Circulating pump Q4 ¦ El imm
heater DHW K6 ¦ Collector pump Q5 ¦
Cons circuit pump VK1 Q15 ¦ Boiler pump
Q1 ¦ Bypass pump Q12 ¦ Alarm output K10
¦ 2nd pump speed HC1 Q21 ¦ 2nd pump
speed HC2 Q22 ¦ 2nd pump speed HC3
Q23 ¦ Heat circuit pump HC3 Q20 ¦ Cons
circuit pump VK2 Q18 ¦ System pump Q14
¦ Heat gen shutoff valve Y4 ¦ Solid fuel
boiler pump Q10 ¦ Time program 5 K13 ¦
Buffer return valve Y15 ¦ Solar pump ext
exch K9 ¦ Solar ctrl elem buffer K8 ¦ Solar
ctrl elem swi pool K18 ¦ Swimming pool
pump Q19 ¦ Cascade pump Q25 ¦ St tank
transfer pump Q11 ¦ DHW mixing pump
Q35 ¦ DHW interm circ pump Q33 ¦ Heat
request K27 ¦ Refrigeration request K28 ¦
Heat circuit pump HC1 Q2 ¦ Heat circuit
pump HC2 Q6 ¦ DHW ctrl elem Q3 ¦
Instant heater ctrl elem Q34 ¦ Water filling
K34 ¦ 2nd boiler pump speed Q27 ¦ Status
output K35 ¦ Status information K36 ¦ Flue
gas damper K37 ¦ Fan shutdown K38 ¦ dT
controller 1 K21 ¦ dT controller 2 K22
Boiler pump Q1 -
5891 Relay output QX2
None ¦ Circulating pump Q4 ¦ El imm heater DHW
K6 ¦ Collector pump Q5 ¦ Cons circuit pump VK1
Q15 ¦ Boiler pump Q1 ¦ Bypass pump Q12 ¦ Alarm
output K10 ¦ 2nd pump speed HC1 Q21 ¦ 2nd
pump speed HC2 Q22 ¦ 2nd pump speed HC3 Q23
Relay Output QX2
None ¦ Circulating pump Q4 ¦ El imm
heater DHW K6 ¦ Collector pump Q5 ¦
Cons circuit pump VK1 Q15 ¦ Boiler pump
Q1 ¦ Bypass pump Q12 ¦ Alarm output K10
¦ 2nd pump speed HC1 Q21 ¦ 2nd pump
Relay output QX2
None ¦ Circulating pump Q4 ¦ El imm
heater DHW K6 ¦ Collector pump Q5 ¦
Cons circuit pump VK1 Q15 ¦ Boiler pump
Q1 ¦ Bypass pump Q12 ¦ Alarm output K10
¦ 2nd pump speed HC1 Q21 ¦ 2nd pump
None -
