104/267
Building Technologies Basic documentation LMV37.4... CC1P7546en
10 Electronic ratio control 17.12.2018
10 Electronic ratio control
10.1 General
Electronic ratio control is used to control the burner’s actuators depending on burner
output. It is possible to connect 2 actuators and, optionally, 1 VSD.
Resolution is 0.1° with the actuators and 0.1% with the VSD. Output can be regulated in
increments of 0.1% in modulating mode and with a maximum of 3 stages in multistage
mode.
To reduce the electric power required for the actuators, they are never operated
simultaneously, but in successive order, or alternately.
10.2 Behavior outside the operating positions
Outside their operating positions, the actuators approach the different positions in
successive order.
The program phase determines the position to be approached.
10.2.1 Traveling speed
The running speed of the actuators is fixed at 5 seconds for a positioning angle of 90°
for SQM33.4, SQM33.5, and SQN1.
The speed is 10 seconds for a positioning angle of 90° for SQM33.6.
The SQM33.7 requires 17 seconds for a positioning angle of 90°.
The ramp speed of the VSD can be adjusted separately for higher and lower speeds.
No. Parameter
522 Ramp up
523 Ramp down
The setting also applies to the operating position (refer to chapter Operating position).
10.2.2 Home position
This position is approached in the Home run (10), Standby (12) and Lockout position
(00) phases.
The position can be set via the following parameters:
Parameter Actuator
501.00 Idle position fuel actuator
502.00 Idle position air actuator
503.00 Idle speed VSD
