220/267

Building Technologies Basic documentation LMV37.4... CC1P7546en

27 Parameter level 17.12.2018

ESC

mi n

Bild 156/0707

The warm settings for fuel-air ratio control of the LMV37.4 have now been configured.

27.11.12 Cold settings for multistage mode («Lo 2-stage» and «Lo 3-stage»)



Note

Refer to chapters Warm settings for «Lo 2-stage» and «Lo 3-stage»!

But with no flame, no actuator travel and no automatic operation after the settings

have been made.

If run is shown in the display, the following must be observed:

mi n

Bild 113/0707

Identification of start for setting the curve.



Note!

You now have the option of pressing

ESC

to continue with the cold setting for

the LMV37.4.
