189/267

Building Technologies Basic documentation LMV37.4... CC1P7546en

27 Parameter level 17.12.2018

27.6 Structure of parameter levels

The parameters are assigned to different levels.

Fuel-air ratio curves

(primary setting)

Entering the password

Basic unit

Internal parameter

(password level)

Fuel air ratio

Actuators

Error history

Process data

Bild 384e/1209

Basic unit

reset

/reset

reset

Figure 103: Structure of parameter levels



Note

The following sections explain the operating philosophy behind the parameter levels using a

number of examples.

Caution!

Pay special attention to chapter Safety notes on settings and parameter settings!
