27.11.9 Interpolating the curvepoints
/
reset
P
Vh
mi n
s%
Bild 113/0707
Identification of start for setting the curve
parameters.
Example 1 = gas modulating
P0, P1 and P9 are set as described: Curvepoint Value 1
fuel
Value 2
air
P0
30.0 22.0
P1
32.0 24.0
P9
80.0 90.0
P2 through P8 have automatically been
calculated:
Curvepoint Value 1
fuel
Value 2
air
P2
38.0 32.3
P3
44.0 40.5
P4
50.0 48.8
P5
56.0 57
P6
62.0 65.3
P7
68.0 73.5
P8
74.0 81.8
P5 shall now be changed:
/
reset
P
Vh
mi n
s%
Bild 136/0707
F
or
A
P
Vhmins%
Bild 137/0707
Keep
F
or
A
depressed.
Example:
F
F
or
A
and
or
P
Vhmins %
Bild 138/0707
Press
or to change the value as
required.
Example: 50.0
