Siemens LMV37.4 Series User Manual

25/267
Building Technologies Basic documentation LMV37.4... CC1P7546en
4 Technical Data 17.12.2018
4.1.3 Analog output / load output X74 pin 3
Accuracy of output voltage ±1%
4.1.4 Cable lengths
 Mains line AC 120 V / AC 230 V Max. 100 m (100 pF/m)
 Display, BC interface For installation under the burner hood or
in the control panel
Max. 3 m (100 pF/m)
 Load controller X5-03 Max. 20 m (100 pF/m)
 Load controller X64 (24 mA) Max. 20 m (100 pF/m)
 Safety loop / burner flange (total) Max. 20 m (100 pF/m)
 External lockout reset button Max. 20 m (100 pF/m)
 Safety valve Max. 20 m (100 pF/m)
 Load output ¹) Max. 10 m (100 pF/m)
 VSD control ¹)²) Max. 3 m (100 pF/m)
 Speed input Max. 3 m (100 pF/m)
 Fuel valve V1 / V2 / V3 Max. 3 m (100 pF/m)
 Pilot valve Max. 3 m (100 pF/m)
 Ignition transformer Max. 3 m (100 pF/m)
 Other lines Max. 3 m (100 pF/m)
¹) Do not run the cable together with other cables. If not observed, hum voltage might
cause electromagnetic interference
²) Shorter cable length due to closed control loop
Specification as per EN 60730-1
Type of shutdown or interruption of each circuit
Shutdown with microswitch
1-pole
Mode of operation
Type 2 B
4.1.5 Cross-sectional areas
The cross-sectional areas of the mains power lines (L, N, and PE) and, if required, the
safety loop (safety limit thermostat, water shortage, etc.) must be sized for rated
currents according to the selected external primary fuse.
The cross-sectional areas of the other cables must be sized in accordance with the
internal unit fuse (max. 6.3 AT).
Min. cross-sectional area 0.75 mm² (single-core or multi-core as per
VDE 0100)
Cable insulation must meet the relevant temperature requirements and environmental
conditions.
Fuses (F1) used inside the LMV37.4 6.3 AT DIN EN 60127 2 / 5
4.1.6 Connections of actuators
The ready connected actuator cables must not be extended.
