Siemens LMV37.4 Series User Manual

24/267
Building Technologies Basic documentation LMV37.4... CC1P7546en
4 Technical Data 17.12.2018
Individual contact loading:
Fan motor contactor
 Rated voltage
- LMV37.420A1
- LMV37.400A2
AC 120 V, 50 / 60 Hz
AC 230 V, 50 / 60 Hz
 Rated current
- LMV37.420A1
- LMV37.400A2
2 A
1,6 A pilot duty load declaration to UL372
 Power factor Cos >0.4
Alarm output
 Rated voltage
- LMV37.420A1
- LMV37.400A2
AC 120 V, 50 / 60 Hz
AC 230 V, 50 / 60 Hz
 Rated current 1 A
 Load factor Cos >0.4
Ignition transformer
 Rated voltage
- LMV37.420A1
- LMV37.400A2
AC 120 V, 50 / 60 Hz
AC 230 V, 50 / 60 Hz
 Rated current
- LMV37.420A1
- LMV37.400A2
2 A
1.6 A pilot duty load declaration to UL372
or
250 VA ignition load declaration to UL372
 Power factor Cos >0.2
Fuel valves
 Rated voltage
- LMV37.420A1
- LMV37.400A2
AC 120 V, 50 / 60 Hz
AC 230 V, 50 / 60 Hz
 Rated current
- LMV37.420A1
- LMV37.400A2
2 A
1.6 A pilot duty load declaration to UL372
 Power factor Cos >0.4
Operation display
 Rated voltage
- LMV37.420A1
- LMV37.400A2
AC 120 V, 50 / 60 Hz
AC 230 V, 50 / 60 Hz
 Rated current 0.5 A
 Power factor Cos >0.4
Safety valve (magnetic clutch / oil pump)
 Rated voltage
- LMV37.420A1
- LMV37.400A2
AC 120 V, 50 / 60 Hz
AC 230 V, 50 / 60 Hz
 Rated current
- LMV37.400A2
- LMV37.420A1
2 A
1,6 A pilot duty load declaration to UL372
 Power factor Cos >0.4
Connections for pressure switch
 Rated voltage
- LMV37.420A1
- LMV37.400A2
AC 120 V, 50 / 60 Hz
AC 230 V, 50 / 60 Hz
 Rated current 1.5 mA
 Power factor ---
Power supply for pressure switch-max / POC (X5-02 pin 3)
 IaMax <10 mA
