Building Technologies Basic documentation LMV37.4... CC1P7546en
27 Parameter level 17.12.2018
27.11.13 Intensity of flame during curve settings
When setting the curve and the curvepoint is displayed, you can press
/
reset
to show the
intensity of flame. When pressing the button for >1 s, a change to parameter 954 is
made; when releasing the button, you return to the curvepoint.
P
V
h
mi n
s%
Bild 123/0707
Example: Curvepoint Low-flame position P1.
/
reset
>1 s
Change to parameter 954
Parameter 954: flashes.
The intensity of flame in % is shown on the right.
Example: 954: 0.0
/
reset
P
V
h
mi n
s%
Bild 123/0707
Release
/
reset
to return to curvepoint Low-fire
position P1.
