Building Technologies Basic documentation LMV37.4... CC1P7546en

11 Actuators X53 / X54 17.12.2018

No. Parameter

606

Tolerance limit of position monitoring (0.1°)

Index 0 = fuel

Index 1 = air

Greatest position error where an error is securely detected

 error detection band: (parameter 606 -0.6°) up to parameter 606

Error

code

Diagnostic

code

Meaning for the LMV37.4

86 0 Position error fuel actuator

87 0 Position error air actuator

Default Chapter3
